Ferrari F80 — [ENGINE] - B.08.01 - CYLINDER HEADS - RH HEAD (diagram 0011)
Exploded view of the [engine] - b.08.01 - cylinder heads - rh head on the Ferrari F80, with 36 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari F80 [ENGINE] - B.08.01 - CYLINDER HEADS - RH HEAD exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/f80/0011.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 255442 | Ferrari Oil Pressure Regulator Valve - 255442 | Superseded | Order 801187 instead | |
| 269227 | Ferrari Oil Pressure Regulator Valve - 269227 | Superseded | Order 801187 instead | |
| 296017 | Ferrari Oil Pressure Regulator Valve - 296017 | Superseded | Order 801187 instead | |
| 745651 | Ferrari RH Cylinder Bank Coil Shield - 745651 | $368.79 | Special order, ships in 7-14 days | |
| 14433121 | Ferrari Screw - 14433121 | Superseded | Order 231617 instead | |
| 300499 | Ferrari Screw - 300499 | $1.44 | Special order, ships in 7-14 days | |
| 11197779 | Ferrari Washer - 11197779 | Superseded | Order 11197774 instead | |
| 2 | 801187 | Ferrari Oil Pressure Regulator Valve - 801187 | $368.79 | Available, ships in 3-6 days |
| 3 | 857028 | Ferrari STUD BOLT - 857028 | Price on request | Contact us for price and availability |
| 4 | 856501 | Ferrari NUT - 856501 | $14.99 | Special order, ships in 7-14 days |
| 5 | 857107 | Ferrari Damping Plate - 857107 | $8.72 | Special order, ships in 7-14 days |
| 6 | 899222 | Ferrari Plug - 899222 | $18.11 | Special order, ships in 7-14 days |
| 7 | 784976 | Ferrari Stud Bolt - 784976 | $68.92 | Special order, ships in 7-14 days |
| 8 | 11197774 | Ferrari Conic Washer 6.4x12x1.2 - 11197774 | $0.12 | Available, ships in 3-6 days |
| 9 | 899148 | Ferrari Plug - 899148 | $13.95 | Special order, ships in 7-14 days |
| 10 | 55015938 | Ferrari BRACKET - 55015938 | Price on request | Contact us for price and availability |
| 11 | 231617 | Ferrari Screw M6 x 18 TCEI - 231617 | Superseded | Order 14433124 instead |
| 12 | 226902 | Ferrari SCREW - 226902 | Price on request | Contact us for price and availability |
| 13 | 296075 | Ferrari Washer - 296075 | $2.38 | Available, ships in 3-6 days |
| 14 | 814799 | Ferrari Stud Bolt - 814799 | $16.94 | Special order, ships in 7-14 days |
| 15 | 230871 | Ferrari Screw - 230871 | $7.42 | Special order, ships in 7-14 days |
| 16 | 55043434 | Ferrari Tappet Insert - 55043434 | $664.78 | Special order, ships in 7-14 days |
| 17 | 55043432 | Ferrari Mechanical Pin - 55043432 | $15.29 | Special order, ships in 7-14 days |
| 18 | 342272 | Ferrari Non Return Valve - 342272 | $20.37 | Special order, ships in 7-14 days |
| 19 | 14454381 | Ferrari O-Ring Seal - 14454381 | $2.59 | Special order, ships in 7-14 days |
| 20 | 14450581 | Ferrari Gasket - 14450581 | $7.19 | Special order, ships in 7-14 days |
| 21 | 271125 | Ferrari Cylinder Head Nut - 271125 | $14.39 | Available, ships in 3-6 days |
| 22 | 271129 | Ferrari Washer - 271129 | $2.38 | Available, ships in 3-6 days |
| 23 | 226901 | Ferrari SCREW - 226901 | Price on request | Contact us for price and availability |
| 24 | 829568 | Ferrari Chain Cooling Nozzle Assembl - 829568 | $93.40 | Special order, ships in 7-14 days |
| 25 | 315493 | Ferrari Screw - 315493 | $2.13 | Special order, ships in 7-14 days |
| 26 | 935821 | Ferrari Stud Bolt - 935821 | $5.63 | Special order, ships in 7-14 days |
| 27 | 226900 | Ferrari SCREW - 226900 | Price on request | Contact us for price and availability |
| 28 | 55005787 | Ferrari RH Cylinder Bank Coil Shield - 55005787 | $368.79 | Special order, ships in 7-14 days |
| 29 | 797723 | Ferrari Screw - 797723 | $0.86 | Special order, ships in 7-14 days |
| 30 | 968580 | Ferrari RH Head Gasket - 968580 | $541.67 | Special order, ships in 7-14 days |
