Ferrari F80 — [ENGINE] - B.15 - INJECTION CONTROL (diagram 0020)
Exploded view of the [engine] - b.15 - injection control on the Ferrari F80, with 7 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari F80 [ENGINE] - B.15 - INJECTION CONTROL exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/f80/0020.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 14432221 | Ferrari Screw - 14432221 | Superseded | Order 231619 instead | |
| 14432224 | Ferrari Screw M6 x 22 - 14432224 | Superseded | Order 231619 instead | |
| 1 | 743252 | Ferrari Corpo Farfallato Motorizz - 743252 | $737.61 | Special order, ships in 7-14 days |
| 2 | 55039394 | Ferrari COMPL. SPACER FOR RH THROTTLE BODY - 55039394 | Price on request | Contact us for price and availability |
| 3 | 55039395 | Ferrari COMPL. SPACER FOR LH THROTTLE BODY - 55039395 | Price on request | Contact us for price and availability |
| 4 | 231624 | Ferrari Allen Screw M6 x 45 - 231624 | Superseded | Order 14305924 instead |
| 5 | 231619 | Ferrari Screw M6 x 22 - 231619 | $0.54 | Available, ships in 3-6 days |
