Ferrari F80 — [ENGINE] - B.26 - ENGINE HEAT EXCHANGER (diagram 0031)
Exploded view of the [engine] - b.26 - engine heat exchanger on the Ferrari F80, with 6 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari F80 [ENGINE] - B.26 - ENGINE HEAT EXCHANGER exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/f80/0031.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 745881 | Ferrari Filler For Under Heat Exchan - 745881 | $393.38 | Special order, ships in 7-14 days | |
| 216568 | Ferrari Screw 6x30 - 216568 | Superseded | Order 231621 instead | |
| 1 | 55042596 | Ferrari HEAT EXCHANGER - 55042596 | Price on request | Special order, ships in 7-14 days |
| 3 | 778452 | Ferrari Heat Exchanger Gasket - 778452 | $9.37 | Special order, ships in 7-14 days |
| 4 | 987940 | Ferrari Filler For Under Heat Exchan - 987940 | $181.93 | Special order, ships in 7-14 days |
| 5 | 231621 | Ferrari Allen Screw M6 x 30 TCEI - 231621 | $0.73 | Available, ships in 3-6 days |
