Ferrari F80 — [MECHANICAL SYSTEM] - D.04.01 - AIR FILTER AIR INTAKE AND DUCTS (diagram 0052)
Exploded view of the [mechanical system] - d.04.01 - air filter air intake and ducts on the Ferrari F80, with 13 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari F80 [MECHANICAL SYSTEM] - D.04.01 - AIR FILTER AIR INTAKE AND DUCTS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/f80/0052.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 55061201 | Ferrari COMPL. LH FILTER BOX - 55061201 | Price on request | Contact us for price and availability |
| 1 | 55060979 | Ferrari COMPL. RH FILTER BOX - 55060979 | Price on request | Contact us for price and availability |
| 2 | 55009887 | Ferrari V-Clamp - 55009887 | $350.16 | Special order, ships in 7-14 days |
| 3 | 55038005 | Ferrari COMPL. BELLOWS - 55038005 | Price on request | Contact us for price and availability |
| 4 | 303232 | Ferrari Collar - 303232 | $10.04 | Available, ships in 3-6 days |
| 5 | 859736 | Ferrari Sensore Di Pressione E Tempe - 859736 | $83.03 | Special order, ships in 7-14 days |
| 6 | 256323 | Ferrari Screw 5x16 - 256323 | $0.98 | Available, ships in 3-6 days |
| 7 | 797729 | Ferrari Screw - 797729 | $1.61 | Special order, ships in 7-14 days |
| 8 | 789073 | Ferrari Washer - 789073 | $0.59 | Special order, ships in 7-14 days |
| 9 | 103549 | Ferrari Grommet - 103549 | $2.80 | In stock |
| 10 | 149707 | Ferrari Spacer - 149707 | $2.13 | Available, ships in 3-6 days |
| 11 | 797723 | Ferrari Screw - 797723 | $0.86 | Special order, ships in 7-14 days |
| 12 | 296781 | Ferrari Hose Clamp - 296781 | $5.59 | In stock |
