Ferrari F80 — [MECHANICAL SYSTEM] - D.29 - COMPLETE WHEELS (diagram 0086)
Exploded view of the [mechanical system] - d.29 - complete wheels on the Ferrari F80, with 16 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari F80 [MECHANICAL SYSTEM] - D.29 - COMPLETE WHEELS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/f80/0086.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 55075483 | Ferrari Hubcap - 55075483 | $102.78 | Special order, ships in 7-14 days | |
| 1 | 55003432 | Ferrari FRONT WHEEL - 55003432 | $48,859.04 | Special order, ships in 7-14 days |
| 1 | 818240 | Ferrari Front Wheel - 818240 | $50,212.81 | Special order, ships in 7-14 days |
| 1 | 55003435 | Ferrari REAR WHEEL - 55003435 | $53,988.27 | Special order, ships in 7-14 days |
| 1 | 818242 | Ferrari Rear Wheel - 818242 | $54,872.76 | Special order, ships in 7-14 days |
| 2 | 854399 | Ferrari Titanium Wheel Bolts M14 Mo. - 854399 | $344.21 | Available, ships in 3-6 days |
| 3 | 55009282 | Ferrari Hubcap - 55009282 | $295.43 | Special order, ships in 7-14 days |
| 3 | 55029968 | Ferrari Hubcap - 55029968 | $590.91 | Special order, ships in 7-14 days |
| 3 | 964077 | Ferrari Hubcap - 964077 | Superseded | Order 55075483 instead |
| 4 | 913102 | Ferrari Tyre Valve - 913102 | $30.57 | Available, ships in 3-6 days |
| 4 | 913104 | Ferrari Tyre Valve - 913104 | $37.13 | Special order, ships in 7-14 days |
| 5 | 939581 | Ferrari Tyre Pressure Monitoring System Wheel Sensor - 939581 | $393.38 | Available, ships in 3-6 days |
| 6 | 11096693 | Ferrari Adhesive Wheel Balancer Weight - 11096693 | $24.32 | Special order, ships in 7-14 days |
| 6 | 308296 | Ferrari Adhesive Wheel Balancer Weight - 308296 | $24.32 | Special order, ships in 7-14 days |
| 8 | 70008176 | Ferrari Replacement Kit For Aluminiu - 70008176 | $4,478.96 | Special order, ships in 7-14 days |
| 9 | 70008177 | Ferrari Stud Bolt Seat Replacement K - 70008177 | $1,395.26 | Special order, ships in 7-14 days |
