Ferrari F80 — [MECHANICAL SYSTEM] - D.37 - PLATES (diagram 0095)
Exploded view of the [mechanical system] - d.37 - plates on the Ferrari F80, with 22 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari F80 [MECHANICAL SYSTEM] - D.37 - PLATES exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/f80/0095.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 255167 | Ferrari Engine Oil Check Label - 255167 | Superseded | Order 262089 instead | |
| 258126 | Ferrari Engine Oil Check Label - 258126 | Superseded | Order 262089 instead | |
| 234909 | Ferrari Oil Level Check Plate - 234909 | $13.93 | Special order, ships in 7-14 days | |
| 2 | 829199 | Ferrari 'Fuels' Label - 829199 | $5.14 | Special order, ships in 7-14 days |
| 3 | 924030 | Ferrari Targhetta Procedura Rifornim - 924030 | $15.72 | Special order, ships in 7-14 days |
| 4 | 55040130 | Ferrari ENGINE/GEARBOX OIL SPECIFICATIONS LABEL - 55040130 | Price on request | Contact us for price and availability |
| 5 | 262089 | Ferrari Oil Level Check Plate - 262089 | $20.56 | Available, ships in 3-6 days |
| 6 | 303010 | Ferrari Warning Label On Terminal Clamp - 303010 | $12.02 | Special order, ships in 7-14 days |
| 7 | 297529 | Ferrari Radiator Contains Antifreeze Label - 297529 | $11.35 | Available, ships in 3-6 days |
| 8 | 279667 | Ferrari High Voltage Warning Label - 279667 | $24.55 | Special order, ships in 7-14 days |
| 11 | 55045278 | Ferrari REFRIGERANT GAS SAE LABEL - 55045278 | Price on request | Contact us for price and availability |
| 12 | 160889 | Ferrari Brake Fluid Reservoir Label - 160889 | $5.39 | Available, ships in 3-6 days |
| 14 | 180092 | Ferrari Low Beam Approval Label - 180092 | $1.84 | Available, ships in 3-6 days |
| 15 | 55046662 | Ferrari E-LATCH EMERGENCY PROCEDURE LABEL - 55046662 | Price on request | Contact us for price and availability |
| 16 | 194621 | Ferrari Tyre Pressure Warning Label - 194621 | $36.86 | Special order, ships in 7-14 days |
| 17 | 293457 | Ferrari Max Speed With Winter Tyres Label - 293457 | $29.48 | Special order, ships in 7-14 days |
| 18 | 55045211 | Ferrari CARBON WHEEL WARNING LABEL - 55045211 | Price on request | Contact us for price and availability |
| 19 | 55009649 | Ferrari Tyre Pressure Label Micheli - 55009649 | $24.34 | Special order, ships in 7-14 days |
| 19 | 55012108 | Ferrari TYRE PRESSURE LABEL, MICHELIN TYRES - 55012108 | Price on request | Contact us for price and availability |
| 21 | 12858780 | Ferrari Adhesive Unleaded Petrol/Gasoline Label - 12858780 | $6.11 | Special order, ships in 7-14 days |
| 22 | 55045546 | Ferrari RADIATOR LABEL - 55045546 | Price on request | Contact us for price and availability |
| 25 | 334592 | Ferrari Mercury Content Label - 334592 | Price on request | Contact us for price and availability |
