Ferrari F80 — [VEHICLE TRIM] - E.01.02 - STRUCTURES AND ELEMENTS CENTRE OF VEHICLE (diagram 0099)
Exploded view of the [vehicle trim] - e.01.02 - structures and elements centre of vehicle on the Ferrari F80, with 17 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari F80 [VEHICLE TRIM] - E.01.02 - STRUCTURES AND ELEMENTS CENTRE OF VEHICLE exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/f80/0099.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 55021269 | Ferrari BLACK BODY - 55021269 | Price on request | Contact us to order |
| 2 | 55019470 | Ferrari Gasket - 55019470 | $722.24 | Special order, ships in 7-14 days |
| 3 | 958067 | Ferrari Screw - 958067 | $5.65 | Special order, ships in 7-14 days |
| 4 | 14447078 | Ferrari Washer D. 5.5 - 15 x 1 - 14447078 | $0.54 | Special order, ships in 7-14 days |
| 5 | 202447 | Ferrari SCREW - 202447 | Price on request | Contact us for price and availability |
| 6 | 202451 | Ferrari WASHER - 202451 | Price on request | Contact us for price and availability |
| 7 | 86021400 | Ferrari Screw - 86021400 | $6.77 | Special order, ships in 7-14 days |
| 8 | 86021500 | Ferrari Washer - 86021500 | $16.18 | Special order, ships in 7-14 days |
| 9 | 14446924 | Ferrari Washer - 14446924 | $0.54 | Available, ships in 3-6 days |
| 10 | 202446 | Ferrari SCREW - 202446 | Price on request | Contact us for price and availability |
| 11 | 202452 | Ferrari WASHER - 202452 | Price on request | Contact us for price and availability |
| 12 | 14331324 | Ferrari Allen Head Bolt M 12X1.25X40 - 14331324 | $4.14 | Special order, ships in 7-14 days |
| 13 | 13507434 | Ferrari Flat Washer 12 - 13507434 | $2.59 | Special order, ships in 7-14 days |
| 14 | 202450 | Ferrari SCREW - 202450 | Price on request | Contact us for price and availability |
| 15 | 85833900 | Ferrari Screw M5 x 16 TBFTX - 85833900 | $0.65 | Available, ships in 3-6 days |
| 16 | 749942 | Ferrari Adjustment Shim - 749942 | $12.04 | Special order, ships in 7-14 days |
| 17 | 231623 | Ferrari Screw M6 x 40 TCEI - 231623 | $1.02 | Available, ships in 3-6 days |
