Ferrari F80 — [VEHICLE TRIM] - E.7 - REAR SUBFRAME (diagram 0106)
Exploded view of the [vehicle trim] - e.7 - rear subframe on the Ferrari F80, with 31 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari F80 [VEHICLE TRIM] - E.7 - REAR SUBFRAME exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/f80/0106.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 86149600 | Ferrari Screw - 86149600 | Superseded | Order 14305326 instead | |
| 12643711 | Ferrari Washer - 12643711 | Superseded | Order 12643724 instead | |
| 12643721 | Ferrari Washer - 12643721 | Superseded | Order 12643724 instead | |
| 14499301 | Ferrari Washer - 14499301 | Superseded | Order 12643724 instead | |
| 2 | 55003007 | Ferrari COMPL. ENGINE COMPARTMENT LID LOCK MOUNTING BRACKET - 55003007 | Price on request | Contact us for price and availability |
| 3 | 81591700 | Ferrari Screw TE M6 x 18 with washer - 81591700 | $4.12 | Available, ships in 3-6 days |
| 4 | 830401 | Ferrari Lock Bracket - Thickness 1mm - 830401 | $16.45 | Special order, ships in 7-14 days |
| 5 | 16286121 | Ferrari Screw M6 x 20 - 16286121 | $1.23 | Available, ships in 3-6 days |
| 6 | 302843 | Ferrari Washer - 302843 | $5.04 | Special order, ships in 7-14 days |
| 7 | 55036080 | Ferrari SHIM - 55036080 | Price on request | Contact us for price and availability |
| 8 | 16285127 | Ferrari Screw M5 x 16 - 16285127 | $1.05 | Special order, ships in 7-14 days |
| 9 | 13577701 | Ferrari Washer 5.15 - 15 x 1.2 - 13577701 | $0.19 | Available, ships in 3-6 days |
| 10 | 298365 | Ferrari Split Washer - 298365 | $14.62 | Special order, ships in 7-14 days |
| 13 | 85629300 | Ferrari Screw M6 x 20 - 85629300 | $1.17 | Available, ships in 3-6 days |
| 14 | 12643727 | Ferrari Shim - 12643727 | $0.38 | Available, ships in 3-6 days |
| 15 | 55037272 | Ferrari SHIM - 55037272 | Price on request | Contact us for price and availability |
| 16 | 55012504 | Ferrari COMPL. RH INTERCOOLER FASTENER BRACKET - 55012504 | Price on request | Contact us for price and availability |
| 17 | 55012495 | Ferrari COMPL. LH INTERCOOLER FASTENER BRACKET - 55012495 | Price on request | Contact us for price and availability |
| 18 | 995393 | Ferrari COMPL. RH REAR RADIATOR FASTENER BRACKET - 995393 | Price on request | Contact us for price and availability |
| 20 | 995395 | Ferrari COMPL. BUMPER FASTENER BRACKET - 995395 | Price on request | Contact us for price and availability |
| 21 | 16286127 | Ferrari Screw 6x20 - 16286127 | $0.82 | Available, ships in 3-6 days |
| 22 | 12643724 | Ferrari/Maserati Washer - 12643724 | $0.20 | In stock |
| 23 | 87549700 | Ferrari Shim - 87549700 | $6.96 | Special order, ships in 7-14 days |
| 24 | 993024 | Ferrari COMPL. RH INTERCOOLER FASTENER BRACKET - 993024 | Price on request | Contact us for price and availability |
| 25 | 993022 | Ferrari COMPL. LH INTERCOOLER FASTENER BRACKET - 993022 | Price on request | Contact us for price and availability |
| 27 | 231623 | Ferrari Screw M6 x 40 TCEI - 231623 | $1.02 | Available, ships in 3-6 days |
| 28 | 55018353 | Ferrari COMPL. FILLER NECK MOUNTING BRACKET - 55018353 | Price on request | Contact us for price and availability |
| 29 | 14306034 | Ferrari Allen Screw M6 x 50 TCEI - 14306034 | $1.04 | Available, ships in 3-6 days |
| 30 | 14305326 | Ferrari Screw - 14305326 | $2.38 | Special order, ships in 7-14 days |
| 31 | 749942 | Ferrari Adjustment Shim - 749942 | $12.04 | Special order, ships in 7-14 days |
| 31 | 88187400 | Ferrari Spessore Di Regolaz.Ant. Sp. - 88187400 | $8.82 | Special order, ships in 7-14 days |
