Ferrari F80 — [VEHICLE TRIM] - E.10 - REAR LID SUBSTRUCTURE (diagram 0110)
Exploded view of the [vehicle trim] - e.10 - rear lid substructure on the Ferrari F80, with 12 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari F80 [VEHICLE TRIM] - E.10 - REAR LID SUBSTRUCTURE exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/f80/0110.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 12640606 | Ferrari Washer - 12640606 | Superseded | Order 12640678 instead | |
| 12640608 | Ferrari Washer - 12640608 | Superseded | Order 12640678 instead | |
| 12640677 | Ferrari Washer - 12640677 | Superseded | Order 12640678 instead | |
| 2 | 835008 | Ferrari Compl. LH Engine Compartment - 835008 | $615.54 | Special order, ships in 7-14 days |
| 2 | 835010 | Ferrari Compl. RH Engine Compartment - 835010 | $615.54 | Special order, ships in 7-14 days |
| 3 | 85629300 | Ferrari Screw M6 x 20 - 85629300 | $1.17 | Available, ships in 3-6 days |
| 4 | 85882600 | Ferrari Washer - 85882600 | $0.17 | Available, ships in 3-6 days |
| 4 | 12644478 | Ferrari Washer D. 6.45 - 15 x 1 - 12644478 | Superseded | Order 85882600 instead |
| 5 | 65841100 | Ferrari Black Foam Washer - Self Adhesive - 65841100 | $2.13 | Available, ships in 3-6 days |
| 6 | 774877 | Ferrari Washer - 774877 | $1.82 | Special order, ships in 7-14 days |
| 7 | 12640678 | Ferrari Washer 6.15x25x2 - 12640678 | $3.47 | Available, ships in 3-6 days |
| 8 | 13046114 | Ferrari Flanged Nut - 13046114 | $0.31 | Available, ships in 3-6 days |
