Ferrari F80 — [VEHICLE TRIM] - E.16 - REAR SHIELDS (diagram 0119)
Exploded view of the [vehicle trim] - e.16 - rear shields on the Ferrari F80, with 18 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari F80 [VEHICLE TRIM] - E.16 - REAR SHIELDS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/f80/0119.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 12647729 | Ferrari Washer 6.45-21X - 12647729 | $0.13 | Special order, ships in 7-14 days | |
| 1 | 55030702 | Ferrari COMPL. REAR UNDERBODY SHIELD - 55030702 | Price on request | Contact us for price and availability |
| 1 | 55030706 | Ferrari COMPL. REAR UNDERBODY SHIELD - 55030706 | $80,613.82 | Special order, ships in 7-14 days |
| 1 | 55030707 | Ferrari COMPL. REAR UNDERBODY SHIELD - 55030707 | Price on request | Contact us for price and availability |
| 2 | 55031079 | Ferrari LH Rear Dam - 55031079 | $1,329.59 | Special order, ships in 7-14 days |
| 2 | 55031080 | Ferrari RH Rear Dam - 55031080 | $1,329.59 | Special order, ships in 7-14 days |
| 3 | 907300 | Ferrari Screw M5 x 14 TBFTX Nerinox - 907300 | $0.98 | Special order, ships in 7-14 days |
| 4 | 968780 | Ferrari RH VEHICLE LIFT BRACKET - 968780 | Price on request | Contact us for price and availability |
| 5 | 968549 | Ferrari LH VEHICLE LIFT BRACKET - 968549 | Price on request | Contact us for price and availability |
| 6 | 13028734 | Ferrari Allen Screw M8 x 25 - 13028734 | $0.92 | Available, ships in 3-6 days |
| 7 | 283982 | Ferrari Washer - 283982 | $0.79 | Special order, ships in 7-14 days |
| 8 | 985568 | Ferrari Vite Tcti M10X1.5X25+Co+R.Im - 985568 | $14.22 | Special order, ships in 7-14 days |
| 9 | 55005886 | Ferrari COMPL. RH UNDERTRAY FASTENER BRACKET - 55005886 | Price on request | Contact us for price and availability |
| 10 | 55005884 | Ferrari COMPL. LH UNDERTRAY FASTENER BRACKET - 55005884 | Price on request | Contact us for price and availability |
| 11 | 55030874 | Ferrari Screw - 55030874 | $50.31 | Special order, ships in 7-14 days |
| 12 | 55011070 | Ferrari AIR INTAKE - 55011070 | Price on request | Contact us for price and availability |
| 13 | 16285227 | Ferrari Screw M5 x 20 - 16285227 | $0.59 | Available, ships in 3-6 days |
| 14 | 12647727 | Ferrari Washer 6X21 - 12647727 | $0.12 | Special order, ships in 7-14 days |
