Ferrari F80 — [VEHICLE TRIM] - E.20 - ENGINE COMPARTMENT INSULATION (diagram 0123)
Exploded view of the [vehicle trim] - e.20 - engine compartment insulation on the Ferrari F80, with 30 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari F80 [VEHICLE TRIM] - E.20 - ENGINE COMPARTMENT INSULATION exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/f80/0123.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 55003401 | Ferrari BUMPER CROSS MEMBER SHIELD - 55003401 | $489.54 | Special order, ships in 7-14 days |
| 2 | 85629300 | Ferrari Screw M6 x 20 - 85629300 | $1.17 | Available, ships in 3-6 days |
| 3 | 55003129 | Ferrari CABLE HEAT SHIELD - 55003129 | $832.22 | Special order, ships in 7-14 days |
| 4 | 55020865 | Ferrari Rear Lock Heat Shield - 55020865 | $205.58 | Special order, ships in 7-14 days |
| 5 | 55032200 | Ferrari Upper Cable Shield - 55032200 | $222.72 | Special order, ships in 7-14 days |
| 6 | 55017092 | Ferrari Heat Shield - 55017092 | $146.84 | Special order, ships in 7-14 days |
| 7 | 86705000 | Ferrari Screw M5x10 TBFTX - 86705000 | $1.36 | Special order, ships in 7-14 days |
| 8 | 55018316 | Ferrari Roof Heat Shield - 55018316 | $881.17 | Special order, ships in 7-14 days |
| 9 | 55018317 | Ferrari Gearbox Mounting Casting Hea - 55018317 | $1,150.42 | Special order, ships in 7-14 days |
| 10 | 81290900 | Ferrari Screw With Double Washer - 81290900 | $1.42 | In stock |
| 11 | 16297934 | Ferrari Flanged Screw M8 x 18 - 16297934 | $1.30 | Special order, ships in 7-14 days |
| 12 | 13578305 | Ferrari Washer - 13578305 | $0.17 | Available, ships in 3-6 days |
| 13 | 55003125 | Ferrari CROSS MEMBER HEAT SHIELD - 55003125 | $293.71 | Special order, ships in 7-14 days |
| 14 | 299418 | Ferrari Stud Bolt - 299418 | $7.63 | Special order, ships in 7-14 days |
| 15 | 14054577 | Ferrari Domed Nut - 14054577 | $0.59 | Available, ships in 3-6 days |
| 16 | 55059560 | Ferrari INSULATION FOR REAR LID ANTENNA BRACKET - 55059560 | Price on request | Special order, ships in 7-14 days |
| 17 | 55057708 | Ferrari INSULATION FOR REAR LID ANTENNA - 55057708 | Price on request | Special order, ships in 7-14 days |
| 18 | 55021019 | Ferrari RH Parcel Shelf Insulation - 55021019 | $391.61 | Special order, ships in 7-14 days |
| 19 | 55021017 | Ferrari LH Parcel Shelf Insulation - 55021017 | $391.61 | Special order, ships in 7-14 days |
| 20 | 55003407 | Ferrari PARCEL SHELF HATCH INSULATION - 55003407 | $685.34 | Special order, ships in 7-14 days |
| 22 | 14591687 | Ferrari Fixing Button - 14591687 | $0.13 | Available, ships in 3-6 days |
| 23 | 55049465 | Ferrari Tank Insulation - 55049465 | $56.27 | Special order, ships in 7-14 days |
| 24 | 55003410 | Ferrari TUB HATCH INSULATION - 55003410 | $61.16 | Special order, ships in 7-14 days |
| 25 | 55003402 | Ferrari LOWER REAR BULKHEAD INSULATION - 55003402 | $587.44 | Special order, ships in 7-14 days |
| 26 | 55003884 | Ferrari Rear Centre Tunnel Console I - 55003884 | $242.31 | Special order, ships in 7-14 days |
| 27 | 55003408 | Ferrari TUNNEL INSULATION CENTRE SECTION - 55003408 | $215.38 | Special order, ships in 7-14 days |
| 28 | 55003405 | Ferrari CENTRE TUNNEL INSULATION FRONT PART - 55003405 | $242.31 | Special order, ships in 7-14 days |
| 29 | 55003406 | Ferrari FIREWALL INSULATION - 55003406 | $685.34 | Special order, ships in 7-14 days |
| 30 | 67315400 | Ferrari Washer - 67315400 | $0.82 | Special order, ships in 7-14 days |
| 31 | 55003409 | Ferrari CENTRE TUNNEL INSULATION LOWER OUTER SE - 55003409 | $215.38 | Special order, ships in 7-14 days |
