Ferrari F80 — [VEHICLE TRIM] - E.23 - LATERAL AIR INTAKES (diagram 0126)
Exploded view of the [vehicle trim] - e.23 - lateral air intakes on the Ferrari F80, with 21 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari F80 [VEHICLE TRIM] - E.23 - LATERAL AIR INTAKES exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/f80/0126.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 12643711 | Ferrari Washer - 12643711 | Superseded | Order 12643724 instead | |
| 12643721 | Ferrari Washer - 12643721 | Superseded | Order 12643724 instead | |
| 14499301 | Ferrari Washer - 14499301 | Superseded | Order 12643724 instead | |
| 1 | 984197 | Ferrari Compl. RH Engine Compartment - 984197 | $4,161.19 | Special order, ships in 7-14 days |
| 2 | 984195 | Ferrari Compl. LH Engine Compartment - 984195 | $4,161.19 | Special order, ships in 7-14 days |
| 3 | 982755 | Ferrari COMPL. RH INTERCOOLER DUCT - 982755 | $4,403.64 | Special order, ships in 7-14 days |
| 4 | 982753 | Ferrari COMPL. LH INTERCOOLER DUCT - 982753 | $4,403.64 | Special order, ships in 7-14 days |
| 5 | 267798 | Ferrari Plug - 267798 | $15.47 | Special order, ships in 7-14 days |
| 6 | 13046111 | Ferrari Nut 6x6 - 13046111 | $0.73 | Special order, ships in 7-14 days |
| 7 | 85833700 | Ferrari SCREW - 85833700 | $0.65 | Available, ships in 3-6 days |
| 7 | 11566224 | Ferrari Screw 5x14 - 11566224 | $0.77 | Available, ships in 3-6 days |
| 8 | 14447078 | Ferrari Washer D. 5.5 - 15 x 1 - 14447078 | $0.54 | Special order, ships in 7-14 days |
| 9 | 55022020 | Ferrari Lateral Radiator Seal - 55022020 | $41.30 | Special order, ships in 7-14 days |
| 10 | 55022019 | Ferrari Lower Radiator Seal - 55022019 | $17.81 | Special order, ships in 7-14 days |
| 11 | 55031438 | Ferrari Compl. RH Coil Filter Duct - 55031438 | $3,128.46 | Special order, ships in 7-14 days |
| 12 | 55031435 | Ferrari Compl. LH Coil Filter Duct - 55031435 | $3,128.46 | Special order, ships in 7-14 days |
| 13 | 55009759 | Ferrari RH Impluvium Grille - 55009759 | $163.17 | Special order, ships in 7-14 days |
| 14 | 55009757 | Ferrari LH Impluvium Grille - 55009757 | $163.17 | Special order, ships in 7-14 days |
| 15 | 55004822 | Ferrari COMPL. RH LATERAL EXTRUSION - 55004822 | $685.34 | Special order, ships in 7-14 days |
| 16 | 301785 | Ferrari Screw 6x20 - 301785 | $1.36 | Available, ships in 3-6 days |
| 17 | 12643724 | Ferrari/Maserati Washer - 12643724 | $0.20 | In stock |
