Ferrari F80 — [VEHICLE TRIM] - E.24 - REAR AIR INTAKES (diagram 0127)
Exploded view of the [vehicle trim] - e.24 - rear air intakes on the Ferrari F80, with 8 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari F80 [VEHICLE TRIM] - E.24 - REAR AIR INTAKES exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/f80/0127.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 11566224 | Ferrari Screw 5x14 - 11566224 | $0.77 | Available, ships in 3-6 days | |
| 1 | 55026356 | Ferrari RH INVERTER DUCT - 55026356 | $3,333.61 | Special order, ships in 7-14 days |
| 2 | 55026355 | Ferrari LH INVERTER DUCT - 55026355 | $3,333.61 | Special order, ships in 7-14 days |
| 3 | 993126 | Ferrari COMPL. LH TYRE DUCT - 993126 | $2,813.76 | Special order, ships in 7-14 days |
| 3 | 993134 | Ferrari COMPL. RH TYRE DUCT - 993134 | $2,813.76 | Special order, ships in 7-14 days |
| 4 | 85833700 | Ferrari SCREW - 85833700 | $0.65 | Available, ships in 3-6 days |
| 5 | 789073 | Ferrari Washer - 789073 | $0.59 | Special order, ships in 7-14 days |
| 6 | 14447078 | Ferrari Washer D. 5.5 - 15 x 1 - 14447078 | $0.54 | Special order, ships in 7-14 days |
