Ferrari F80 — [VEHICLE TRIM] - E.57.01 - AIR CONDITIONING SYSTEM - FRONT ZONE EVAPORATOR (diagram 0176)
Exploded view of the [vehicle trim] - e.57.01 - air conditioning system - front zone evaporator on the Ferrari F80, with 11 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari F80 [VEHICLE TRIM] - E.57.01 - AIR CONDITIONING SYSTEM - FRONT ZONE EVAPORATOR exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/f80/0176.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 965060 | Ferrari Hvac Airmix Tko Front Airinl - 965060 | Superseded | Order 988473 instead | |
| 1 | 988473 | Ferrari Hvac Airmix Tko Front Airinl - 988473 | $5,395.33 | Special order, ships in 7-14 days |
| 2 | 848717 | Ferrari Kit Coibentazione Gruppo Hva - 848717 | $172.10 | Special order, ships in 7-14 days |
| 3 | 893774 | Ferrari Exhaust Pipe - 893774 | $233.89 | Special order, ships in 7-14 days |
| 4 | 178052 | Ferrari Clip - 178052 | $3.26 | Available, ships in 3-6 days |
| 4 | 296778 | Ferrari Screw Collar 16- 27mm - 296778 | Superseded | Order 178052 instead |
| 5 | 185107 | Ferrari SCREW - 185107 | Price on request | Contact us for price and availability |
| 6 | 272605 | Ferrari STUD BOLT - 272605 | Price on request | Contact us for price and availability |
| 7 | 223027 | Ferrari NUT - 223027 | Price on request | Contact us for price and availability |
| 8 | 89274100 | Ferrari Sensore Temperatura - 89274100 | $157.34 | Special order, ships in 7-14 days |
| 9 | 88712600 | Ferrari Temperature Sensor - 88712600 | $34.94 | Special order, ships in 7-14 days |
