Ferrari F80 — [VEHICLE TRIM] - E.61 - BATTERY INSTALLATION (diagram 0182)
Exploded view of the [vehicle trim] - e.61 - battery installation on the Ferrari F80, with 19 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari F80 [VEHICLE TRIM] - E.61 - BATTERY INSTALLATION exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/f80/0182.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 975266 | Ferrari Compl. Battery Carrier Tray - 975266 | $4,539.93 | Special order, ships in 7-14 days |
| 2 | 55004148 | Ferrari COMPL. REAR BATTERY TRELLIS - 55004148 | $590.91 | Special order, ships in 7-14 days |
| 3 | 256323 | Ferrari Screw 5x16 - 256323 | $0.98 | Available, ships in 3-6 days |
| 4 | 13046114 | Ferrari Flanged Nut - 13046114 | $0.31 | Available, ships in 3-6 days |
| 5 | 55021948 | Ferrari STAFFA FRONTALE BLOCCAGGIO BATTERIA CPL - 55021948 | $233.89 | Special order, ships in 7-14 days |
| 6 | 778833 | Ferrari STAFFA INFERIORE FISSAGGIO BATTERIA - 778833 | $96.01 | Special order, ships in 7-14 days |
| 7 | 986768 | Ferrari Screw - 986768 | $3.26 | Special order, ships in 7-14 days |
| 8 | 55004119 | Ferrari STAFFA FLANGIATA - 55004119 | $83.68 | Special order, ships in 7-14 days |
| 9 | 88187400 | Ferrari Spessore Di Regolaz.Ant. Sp. - 88187400 | $8.82 | Special order, ships in 7-14 days |
| 10 | 55030183 | Ferrari COMPL. EMERGENCY STRAP - 55030183 | Price on request | Contact us for price and availability |
| 11 | 55004842 | Ferrari STAFFA FISSAGGIO CINGHIA CPL - 55004842 | $108.31 | Special order, ships in 7-14 days |
| 12 | 85833900 | Ferrari Screw M5 x 16 TBFTX - 85833900 | $0.65 | Available, ships in 3-6 days |
| 13 | 14447078 | Ferrari Washer D. 5.5 - 15 x 1 - 14447078 | $0.54 | Special order, ships in 7-14 days |
| 14 | 55004134 | Ferrari COMPL. FRONT BATTERY TRELLIS - 55004134 | $1,403.46 | Special order, ships in 7-14 days |
| 15 | 996106 | Ferrari Screw - 996106 | $1.30 | Special order, ships in 7-14 days |
| 16 | 55004126 | Ferrari STAFFA SOSTEGNO TRALICCIO CENTR. CPL - 55004126 | $172.33 | Special order, ships in 7-14 days |
| 17 | 13832614 | Ferrari SCREW - 13832614 | Price on request | Contact us for price and availability |
| 18 | 12643701 | Ferrari Flat Washer - 12643701 | $0.12 | Available, ships in 3-6 days |
| 19 | 55004850 | Ferrari STAFFA FIX CINGHIA EMERGENZA CPL - 55004850 | $172.33 | Special order, ships in 7-14 days |
