Ferrari F80 — [ELECTRICAL SYSTEM] - F.7 - LOW VOLTAGE WIRING HARNESSES (diagram 0190)
Exploded view of the [electrical system] - f.7 - low voltage wiring harnesses on the Ferrari F80, with 40 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari F80 [ELECTRICAL SYSTEM] - F.7 - LOW VOLTAGE WIRING HARNESSES exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/f80/0190.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 140366 | Ferrari Cable Junction Box - 140366 | Superseded | Order 170114 instead | |
| 14039614 | Ferrari NUT - 14039614 | $0.40 | Available, ships in 3-6 days | |
| 14084111 | Ferrari Nut - 14084111 | Superseded | Order 11673111 instead | |
| 153357 | Ferrari Terminal Box - 153357 | Superseded | Order 170114 instead | |
| 120064 | Ferrari Terminal Connection Bloc - 120064 | Superseded | Order 170114 instead | |
| 1 | 55038668 | Ferrari PASSENGER COMPARTMENT CABLE - 55038668 | Price on request | Contact us for price and availability |
| 1 | 55038669 | Ferrari PASSENGER COMPARTMENT CABLE - 55038669 | Price on request | Contact us for price and availability |
| 2 | 55016821 | Ferrari ENGINE COMPARTMENT CABLE - 55016821 | Price on request | Contact us for price and availability |
| 3 | 55038672 | Ferrari DASHBOARD CABLE - 55038672 | Price on request | Contact us for price and availability |
| 3 | 55038673 | Ferrari DASHBOARD CABLE - 55038673 | Price on request | Contact us for price and availability |
| 3 | 55038674 | Ferrari DASHBOARD CABLE - 55038674 | Price on request | Contact us for price and availability |
| 4 | 55038679 | Ferrari PASSENGER SIDE DOOR CABLE - 55038679 | Price on request | Contact us for price and availability |
| 5 | 55038678 | Ferrari DRIVER SIDE DOOR CABLE - 55038678 | Price on request | Contact us for price and availability |
| 6 | 55038682 | Ferrari FRONT BUMPER CABLE - 55038682 | Price on request | Contact us for price and availability |
| 6 | 55038683 | Ferrari FRONT BUMPER CABLE - 55038683 | Price on request | Contact us for price and availability |
| 7 | 55038680 | Ferrari REAR BUMPER CABLE - 55038680 | Price on request | Contact us for price and availability |
| 8 | 989420 | Ferrari FRONT AXLE WIRING HARNESS - 989420 | Price on request | Contact us for price and availability |
| 9 | 55016822 | Ferrari DCT WIRING HARNESS - 55016822 | Price on request | Contact us for price and availability |
| 10 | 55026437 | Ferrari Negative Cable From Dummy Te - 55026437 | $137.87 | Special order, ships in 7-14 days |
| 11 | 995683 | Ferrari RH Negative Dcdc Cable - 995683 | $140.32 | Special order, ships in 7-14 days |
| 12 | 995682 | Ferrari LH Negative Dcdc Cable - 995682 | $120.62 | Special order, ships in 7-14 days |
| 13 | 55026438 | Ferrari Negative Cable From Battery - 55026438 | $270.83 | Special order, ships in 7-14 days |
| 14 | 995340 | Ferrari Airbag ECU Ground Cable - 995340 | $76.30 | Special order, ships in 7-14 days |
| 15 | 55016823 | Ferrari SEMI-CHASSIS GROUND CABLE - 55016823 | Price on request | Contact us for price and availability |
| 16 | 55036041 | Ferrari COVER AIRBAG WIRING HARNESS - 55036041 | Price on request | Contact us for price and availability |
| 17 | 55033678 | Ferrari CENTRE TUNNEL WIRING HARNESS - 55033678 | Price on request | Contact us for price and availability |
| 18 | 55016836 | Ferrari A2B MICROPHONE WIRING HARNESS - 55016836 | Price on request | Contact us for price and availability |
| 19 | 55033679 | Ferrari LH Positive Dcdc Cable - 55033679 | $320.06 | Special order, ships in 7-14 days |
| 20 | 55033680 | Ferrari THIRD STOP LIGHT WIRING HARNESS - 55033680 | Price on request | Contact us for price and availability |
| 21 | 995685 | Ferrari SUSPENSION OIL LEVEL SENSOR WIRING HARNE - 995685 | $76.30 | Special order, ships in 7-14 days |
| 23 | 817373 | Ferrari Upper Node Cover - 817373 | $34.40 | Special order, ships in 7-14 days |
| 25 | 14059111 | Ferrari Flanged Nut M5 - 14059111 | $0.08 | Available, ships in 3-6 days |
| 25 | 14039511 | Ferrari Nut - 14039511 | $0.54 | Available, ships in 3-6 days |
| 26 | 55019107 | Ferrari COMPL. AUXILIARY BATTERY ECU - 55019107 | Price on request | Contact us for price and availability |
| 27 | 14059311 | Ferrari NUT - 14059311 | $0.52 | Available, ships in 3-6 days |
| 28 | 11673111 | Ferrari Nut - 11673111 | $0.52 | Available, ships in 3-6 days |
| 29 | 170114 | Ferrari Terminal Box - 170114 | $86.15 | Available, ships in 3-6 days |
| 30 | 814570 | Ferrari Negative Battery Terminal - 814570 | $68.83 | Special order, ships in 7-14 days |
| 31 | 916302 | Ferrari Engine-Chassis Ground Connec - 916302 | $103.25 | Special order, ships in 7-14 days |
| 32 | 995674 | Ferrari ENGINE-CHASSIS GROUND CONNECTOR BRAID - 995674 | Price on request | Contact us for price and availability |
