Ferrari F80 — [ELECTRICAL SYSTEM] - F.9 - LIGHTING SYSTEMS (diagram 0192)
Exploded view of the [electrical system] - f.9 - lighting systems on the Ferrari F80, with 18 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari F80 [ELECTRICAL SYSTEM] - F.9 - LIGHTING SYSTEMS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/f80/0192.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 10903221 | Ferrari Bolt - 10903221 | Superseded | Order 10903224 instead | |
| 1 | 55061322 | Ferrari RH HEADLAMP - 55061322 | $15,752.23 | Contact us to order |
| 2 | 55061321 | Ferrari LH HEADLAMP - 55061321 | Price on request | Contact us for price and availability |
| 3 | 55030780 | Ferrari RH Front Gasket - 55030780 | $124.74 | Special order, ships in 7-14 days |
| 3 | 55030784 | Ferrari RH Front Gasket - 55030784 | $124.74 | Special order, ships in 7-14 days |
| 4 | 55030778 | Ferrari LH Front Gasket - 55030778 | $124.74 | Special order, ships in 7-14 days |
| 4 | 55030781 | Ferrari LH Front Gasket - 55030781 | $124.74 | Special order, ships in 7-14 days |
| 5 | 10903224 | Ferrari Screw M6 x 40 - 10903224 | $0.50 | Available, ships in 3-6 days |
| 6 | 10523424 | Ferrari Washer D 6.15-18x2 - 10523424 | $0.92 | Available, ships in 3-6 days |
| 7 | 55032752 | Ferrari FRONT LIGHT UNIT - 55032752 | Price on request | Contact us for price and availability |
| 8 | 910850 | Ferrari Rear Fog Light - 910850 | $568.23 | Special order, ships in 7-14 days |
| 9 | 914293 | Ferrari Allen Head Bolt M4X16 - 914293 | $1.11 | Special order, ships in 7-14 days |
| 10 | 995128 | Ferrari RH TAIL LIGHT - 995128 | $3,528.97 | Special order, ships in 7-14 days |
| 11 | 995108 | Ferrari LH TAIL LIGHT - 995108 | $3,528.97 | Special order, ships in 7-14 days |
| 12 | 13832101 | Ferrari Flanged Nut M6 - 13832101 | $0.27 | Available, ships in 3-6 days |
| 13 | 992997 | Ferrari THIRD BRAKE LIGHT - 992997 | $766.01 | Special order, ships in 7-14 days |
| 14 | 935243 | Ferrari Screw TBFTX T20 M4 x 10 Nerinox - 935243 | $0.96 | Special order, ships in 7-14 days |
| 15 | 12642878 | Ferrari Washer - 12642878 | $0.19 | Available, ships in 3-6 days |
