Ferrari F80 — [ELECTRICAL SYSTEM] - F.16 - ADAS (diagram 0199)
Exploded view of the [electrical system] - f.16 - adas on the Ferrari F80, with 20 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari F80 [ELECTRICAL SYSTEM] - F.16 - ADAS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/f80/0199.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 14432221 | Ferrari Screw - 14432221 | Superseded | Order 231619 instead | |
| 14432224 | Ferrari Screw M6 x 22 - 14432224 | Superseded | Order 231619 instead | |
| 1 | 915742 | Ferrari ECU - 915742 | Price on request | Contact us for price and availability |
| 2 | 990305 | Ferrari Accelerator For Magneride System - 990305 | $442.56 | Available, ships in 3-6 days |
| 3 | 764923 | Ferrari Front Crash Sensor - 764923 | $74.29 | Available, ships in 3-6 days |
| 4 | 231620 | Ferrari/Maserati Screw - 231620 | $0.58 | In stock |
| 5 | 764924 | Ferrari LATERAL CRASH SENSOR - 764924 | $74.29 | Special order, ships in 7-14 days |
| 6 | 14059211 | Ferrari Flanged Nut - 14059211 | $0.13 | Available, ships in 3-6 days |
| 7 | 821052 | Ferrari Lateral Crash Sensor - 821052 | $74.29 | Special order, ships in 7-14 days |
| 8 | 231619 | Ferrari Screw M6 x 22 - 231619 | $0.54 | Available, ships in 3-6 days |
| 9 | 996047 | Ferrari Mpc Camera - 996047 | $2,515.00 | Special order, ships in 7-14 days |
| 10 | 786808 | Ferrari Rain And Twilight Sensor - 786808 | $393.38 | Special order, ships in 7-14 days |
| 11 | 893484 | Ferrari Spoiler Mirror Video Cable - 893484 | $130.29 | Special order, ships in 7-14 days |
| 12 | 815940 | Ferrari Mirror Camera - 815940 | $1,083.38 | Special order, ships in 7-14 days |
| 13 | 812891 | Ferrari Screw - 812891 | $0.73 | Special order, ships in 7-14 days |
| 14 | 990171 | Ferrari Rear Camera - 990171 | $2,201.19 | Special order, ships in 7-14 days |
| 15 | 14304220 | Ferrari Screw 5x16 - 14304220 | $0.17 | Available, ships in 3-6 days |
| 16 | 848849 | Ferrari Clip - 848849 | $5.65 | Special order, ships in 7-14 days |
| 17 | 997677 | Ferrari FRONT RADAR UNIT - 997677 | Price on request | Contact us for price and availability |
| 18 | 990172 | Ferrari Surround Camera - 990172 | $1,943.61 | Special order, ships in 7-14 days |
