Ferrari Monza SP1 — [MECHANICAL SYSTEM] - D.3 - ENGINE INJECTION CONTROL (diagram 0050)
Exploded view of the [mechanical system] - d.3 - engine injection control on the Ferrari Monza SP1, with 11 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Monza SP1 [MECHANICAL SYSTEM] - D.3 - ENGINE INJECTION CONTROL exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/monza-sp1/0050.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 14433121 | Ferrari Screw - 14433121 | Superseded | Order 231617 instead | |
| 1 | 337737 | Ferrari Ignition ECU - 337737 | $2,442.40 | Special order, ships in 7-14 days |
| 2 | 338526 | Ferrari RH Motronic Fastener Bracket - 338526 | $164.72 | Special order, ships in 7-14 days |
| 3 | 338527 | Ferrari LH Motronic Fastener Bracket - 338527 | $164.72 | Special order, ships in 7-14 days |
| 4 | 339174 | Ferrari Motronic Central Fastener Br - 339174 | $71.28 | Special order, ships in 7-14 days |
| 5 | 16296924 | Ferrari Screw M6 x 14 TE - 16296924 | $0.54 | Available, ships in 3-6 days |
| 6 | 12647624 | Ferrari Washer D 6.45-16x2 - 12647624 | $0.19 | Available, ships in 3-6 days |
| 7 | 256323 | Ferrari Screw 5x16 - 256323 | $0.98 | Available, ships in 3-6 days |
| 8 | 339487 | Ferrari Connector Fastener Bracket - 339487 | $63.90 | Special order, ships in 7-14 days |
| 9 | 313125 | Ferrari Ignition ECU - 313125 | $2,084.11 | Special order, ships in 7-14 days |
| 10 | 231617 | Ferrari Screw M6 x 18 TCEI - 231617 | Superseded | Order 14433124 instead |
