Ferrari Monza SP1 — [MECHANICAL SYSTEM] - D.11 - FUEL TANK (diagram 0060)

Exploded view of the [mechanical system] - d.11 - fuel tank on the Ferrari Monza SP1, with 62 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari Monza SP1 [MECHANICAL SYSTEM] - D.11 - FUEL TANK exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
198253Ferrari Clip - 198253$7.40Special order, ships in 7-14 days
222826Ferrari Clip - 222826$5.44Special order, ships in 7-14 days
13046011Ferrari Flanged Nut - 13046011$0.73Available, ships in 3-6 days
282074Ferrari Fuel Delivery Pipe Front Section LHD - 282074$129.70Special order, ships in 7-14 days
253597Ferrari LH Fuel Pump Filter - 253597SupersededOrder 282785 instead
14039614Ferrari NUT - 14039614$0.40Available, ships in 3-6 days
181929Ferrari On-Off Valve - 181929$440.56Special order, ships in 7-14 days
253600Ferrari RH Fuel Pump Filter - 253600SupersededOrder 282784 instead
10519401Ferrari Washer - 10519401SupersededOrder 10519424 instead
13550201Ferrari Washer - 13550201SupersededOrder 10519424 instead
1866732Ferrari Serbatoio Carburante Cpl Pom - 866732$13,817.09Contact us to order
2282784Ferrari Fuel Pump with Filter (RH) - 282784$614.90In stock
3282785Ferrari Fuel Pump with Filter (LH) - 282785$614.90Contact us
4239412Ferrari O-Ring - 239412$21.51Available, ships in 3-6 days
4275314Ferrari O-Ring - 275314$12.31Available, ships in 3-6 days
5275998Ferrari Fastener Ring - 275998$120.46Available, ships in 3-6 days
6256323Ferrari Screw 5x16 - 256323$0.98Available, ships in 3-6 days
7238688Ferrari Connector - 238688$88.49Special order, ships in 7-14 days
8237407Ferrari On-Off Valve - 237407$56.52Special order, ships in 7-14 days
9828420Ferrari Bocchettone Carb. Cpl E Tuba - 828420$1,395.20Special order, ships in 7-14 days
9874303Ferrari Bocchettone Carb. Cpl E Tuba - 874303Price on requestContact us for price and availability
10304908Ferrari Screw - 304908$8.93Special order, ships in 7-14 days
11309340Ferrari Bracket With Sheath - 309340$12.99Special order, ships in 7-14 days
1211625714Ferrari SCREW - 11625714$1.02Special order, ships in 7-14 days
13281180Ferrari Rear Fuel Delivery Pipe - 281180$491.74Special order, ships in 7-14 days
14206536Ferrari Clip D.14 - 206536$0.92Special order, ships in 7-14 days
15177553Ferrari Clamp - 177553$0.84Available, ships in 3-6 days
16277364Ferrari Fuel Delivery Pipe Centre Section - 277364$51.62Special order, ships in 7-14 days
1710441490Ferrari/Maserati Retaining Clip - 10441490$1.35In stock
18286193Ferrari Fuel Pipe Fastener Bracket - 286193$36.86Special order, ships in 7-14 days
1910441290Ferrari P Clip Bracket With Sheath 28mm D.10 - 10441290$1.02Available, ships in 3-6 days
20235682Ferrari Clip - 235682$1.36Special order, ships in 7-14 days
21295009Ferrari Fuel Delivery Pipe Front Section LHD - 295009$149.96Special order, ships in 7-14 days
2214040611Ferrari Nut M6 - 14040611$0.57Available, ships in 3-6 days
23125516Ferrari Washer - 125516SupersededOrder 10519424 instead
2310519424Ferrari Washer 1.6mm 6.40x11.95x1.6 - 10519424$0.06Available, ships in 3-6 days
2414059111Ferrari Flanged Nut M5 - 14059111$0.08Available, ships in 3-6 days
2414039511Ferrari Nut - 14039511$0.54Available, ships in 3-6 days
25290771Ferrari Lower Connector Pipe - 290771$688.45Special order, ships in 7-14 days
2613126670Ferrari Collar - 13126670$2.13Available, ships in 3-6 days
26281598Ferrari Collar - 281598SupersededOrder 13126670 instead
27277360Ferrari Heat Shield - 277360$127.82Special order, ships in 7-14 days
2816285127Ferrari Screw M5 x 16 - 16285127$1.05Special order, ships in 7-14 days
2910441890Ferrari P Clip Bracket With Sheath D22 - 10441890$1.17Available, ships in 3-6 days
30263230Ferrari Clip - 263230$2.82Special order, ships in 7-14 days
31290800Ferrari Connector Pipe Mounting Bracket - 290800$110.61Special order, ships in 7-14 days
32286534Ferrari Pipe Mounting Bracket - 286534Price on requestContact us for price and availability
33259508Ferrari Clip 15.8mm-18.5mm - 259508$1.25Special order, ships in 7-14 days
34272086Ferrari RH Fuel Pump - 272086$2,814.21Special order, ships in 7-14 days
35272714Ferrari Rear Inspection Cover Complete - 272714$41.76Special order, ships in 7-14 days
3614040514Ferrari Flanged Nut - 14040514SupersededOrder 13046011 instead
37332702Ferrari LH Fuel Pump - 332702$1,873.35Available, ships in 3-6 days
3810815787Ferrari Clamp - 10815787$0.31Available, ships in 3-6 days
39253408Ferrari Quick Release Stud Bolts - 253408$110.61Special order, ships in 7-14 days
40253407Ferrari Compression Spring - 253407$66.35Special order, ships in 7-14 days
41253409Ferrari Upper Plate - 253409$66.35Special order, ships in 7-14 days
42328592Ferrari Fuel Level Sensor - 328592$393.38Special order, ships in 7-14 days
43254311Ferrari Angle Adaptor - 254311$16.94Special order, ships in 7-14 days
44273479Ferrari Support - 273479$194.22Special order, ships in 7-14 days
45276001Ferrari Ring - 276001$524.51Special order, ships in 7-14 days
46239413Ferrari O-Ring - 239413$9.29Available, ships in 3-6 days
47250480Ferrari Inspection Cap - 250480$46.69Special order, ships in 7-14 days
