Ferrari Monza SP1 — [VEHICLE TRIM] - E.47.01 - DASHBOARD - SUBSTRUCTURE -Not for RHD- (diagram 0149)

Exploded view of the [vehicle trim] - e.47.01 - dashboard - substructure -not for rhd- on the Ferrari Monza SP1, with 67 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari Monza SP1 [VEHICLE TRIM] - E.47.01 - DASHBOARD - SUBSTRUCTURE -Not for RHD- exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
14368371Ferrari Screw Clip - 14368371SupersededOrder 14188971 instead
284147Ferrari Washer - 284147SupersededOrder 308666 instead
1985937730Ferrari Compl. Upper Dashboard - 985937730$37,271.67Contact us to order
2878708Ferrari Driver Side Clear Wind Defle - 878708$1,248.34Special order, ships in 7-14 days
3878979Ferrari Compl. Driver Side Binnacle - 878979$3,907.10Special order, ships in 7-14 days
4766042Ferrari Compl. Binnacle Substructure - 766042$5,979.54Special order, ships in 7-14 days
4836157Ferrari Compl. Binnacle Substructure - 836157$7,823.52Special order, ships in 7-14 days
5834188Ferrari Compl. Backing For Substruct - 834188$8,166.22Special order, ships in 7-14 days
6828125Ferrari Guarnizione Acqua - 828125$204.49Special order, ships in 7-14 days
7848838Ferrari Guarnizione Cover Rlf - 848838$52.19Special order, ships in 7-14 days
8925960Ferrari Lateral Seal - 925960$63.08Special order, ships in 7-14 days
9766117Ferrari Rlf Cover - 766117SupersededOrder 836158 instead
9836158Ferrari Rlf Cover - 836158$1,272.82Special order, ships in 7-14 days
10881351Ferrari Guarnizione Ossatura Top Pla - 881351$18.25Special order, ships in 7-14 days
1187219800Ferrari Rubber Pad - 87219800$3.91Special order, ships in 7-14 days
12836700Ferrari Bracket for Upper Passenger Side Dash Section - 836700$151.74Special order, ships in 7-14 days
13848759Ferrari Compl. RH Upper Dash Section Mounting Bracket - 848759$56.27Special order, ships in 7-14 days
14849577Ferrari Riparo Calore - 849577$215.38Special order, ships in 7-14 days
1514591687Ferrari Fixing Button - 14591687$0.13Available, ships in 3-6 days
16844066Ferrari Guarnizione Antipolvere Rlf - 844066$143.58Special order, ships in 7-14 days
17844350Ferrari Guarnizione Antipolvere Cupo - 844350$16.50Special order, ships in 7-14 days
18918899Ferrari Shim - 918899$13.01Special order, ships in 7-14 days
19918906Ferrari Shim - 918906$13.01Special order, ships in 7-14 days
20828127Ferrari Guarnizione Antifumo - 828127$39.14Special order, ships in 7-14 days
21320034Ferrari Aerocatch Kit - 320034$1,174.90Special order, ships in 7-14 days
22836460Ferrari Aerocatch Pin Fastener Plat - 836460$78.30Special order, ships in 7-14 days
23985900970Ferrari Mono Place Cover Cpl Semilav - 985900970$54,565.20Contact us to order
24901006Ferrari Guarnizione Post Mono Place - 901006$71.78Special order, ships in 7-14 days
25901027Ferrari Guarnizione Lat Mono Place C - 901027$54.38Special order, ships in 7-14 days
26839802Ferrari Perni Rotazione Monoplace Co - 839802$660.87Special order, ships in 7-14 days
27855158Ferrari RH Upper Bracket - SP1 Dashboard - 855158$318.19Special order, ships in 7-14 days
28836285Ferrari LH Upper Bracket - SP1 Dashboard - 836285$78.30Special order, ships in 7-14 days
29881242Ferrari LH Bracket - Single Seat Cover - 881242$709.82Special order, ships in 7-14 days
30881244Ferrari RH Bracket - Single Seat Cover - 881244$709.82Special order, ships in 7-14 days
31881248Ferrari Cover For Lateral Cover Brac - 881248$2,471.06Special order, ships in 7-14 days
32881256Ferrari Cover For Lateral Cover Brac - 881256$2,471.06Special order, ships in 7-14 days
33831300Ferrari Bracket for LH Elastic Fastener - 831300$78.30Special order, ships in 7-14 days
34831306Ferrari Bracket for RH Elastic Fastener - 831306$78.30Special order, ships in 7-14 days
35856572Ferrari BLUETOOTH BRACKET - 856572Price on requestContact us for price and availability
36831604Ferrari Lights Control Bracket - 831604$117.47Special order, ships in 7-14 days
37856890Ferrari INFOLED FASTENER BRACKET - 856890Price on requestContact us for price and availability
38878844Ferrari Complete Body Computer Bracket - 878844$807.74Special order, ships in 7-14 days
3988041000Ferrari Driver Side Lower Air Duct B - 88041000$31.93Special order, ships in 7-14 days
4083853800Ferrari RH Air Con Unit Bracket - 83853800$46.69Available, ships in 3-6 days
41842795Ferrari Upper Passenger Side Cover Fastener Bracket - 842795$34.25Special order, ships in 7-14 days
42833921Ferrari Underdash Trim Fastener Bracket - 833921$73.41Special order, ships in 7-14 days
4384494400Ferrari Lower Under Driver Seat Bracket LHD - 84494400$344.21Special order, ships in 7-14 days
44878845Ferrari Lower RH Bracket - Dashboard - 878845$293.71Special order, ships in 7-14 days
45834231Ferrari LH Lower Bracket - Dashboard - 834231$80.75Special order, ships in 7-14 days
4687895800Ferrari RH Lateral Bracket - 87895800$169.62Special order, ships in 7-14 days
47923029Ferrari RH Lateral Bodyshell Bracket - 923029$166.42Special order, ships in 7-14 days
48923028Ferrari LH Lateral Bodyshell Bracket - 923028$166.42Special order, ships in 7-14 days
4984937900Ferrari OBD Bracket LHD - 84937900$61.45Special order, ships in 7-14 days
5082718500Ferrari Firewall Bracket LHD - 82718500$68.83Special order, ships in 7-14 days
51833923Ferrari Instrument Panel Bracket - 833923$88.09Special order, ships in 7-14 days
52860336Ferrari Compl. Upper Glove Compartment Bracket - 860336$367.14Special order, ships in 7-14 days
5383854000Ferrari LH Air Con Unit Bracket - 83854000$46.69Available, ships in 3-6 days
54842794Ferrari LH Bracket - Dashboard - 842794$66.07Special order, ships in 7-14 days
5514189374Ferrari Clip For Screw - 14189374$0.98Special order, ships in 7-14 days
5680964300Ferrari Temperature Sensor Bracket - 80964300$12.21Special order, ships in 7-14 days
57912715Ferrari Dashboard Cross Member - 912715$4,412.97Special order, ships in 7-14 days
58849369Ferrari Complete Upper Dash Section Fastener Bracket - 849369$110.13Special order, ships in 7-14 days
59308666Ferrari Washer - 308666$3.70Special order, ships in 7-14 days
60839800Ferrari Antenna Fastener Bracket - 839800$48.93Special order, ships in 7-14 days
61952310Ferrari Adjustment Shim - 952310$7.80Special order, ships in 7-14 days
6314188971Ferrari Screw Clip - 14188971$9.07Special order, ships in 7-14 days
641002911Ferrari MEMBRANE KIT, SINGLE SEAT VERSION - 1002911Price on requestContact us for price and availability
