Ferrari Monza SP1 — [VEHICLE TRIM] - E.51.03 - FRONT SEATS - RACING SEAT (diagram 0163)
Exploded view of the [vehicle trim] - e.51.03 - front seats - racing seat on the Ferrari Monza SP1, with 9 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Monza SP1 [VEHICLE TRIM] - E.51.03 - FRONT SEATS - RACING SEAT exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/monza-sp1/0163.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 834178 | Ferrari Monocoque Shell Seat Size L - 834178 | $33,828.94 | Contact us to order |
| 1 | 834176 | Ferrari Monocoque Shell Seat Size M - 834176 | $33,736.08 | Contact us to order |
| 2 | 65806500 | Ferrari SPRING PLATE - 65806500 | $1.25 | Special order, ships in 7-14 days |
| 3 | 85635700 | Ferrari SCREW - 85635700 | $3.47 | Available, ships in 3-6 days |
| 4 | 86768800 | Ferrari SEAT ARCH - 86768800 | $417.97 | Special order, ships in 7-14 days |
| 5 | 86770900 | Ferrari RH GUIDE - 86770900 | $1,745.74 | Special order, ships in 7-14 days |
| 6 | 86771000 | Ferrari LH GUIDE - 86771000 | $1,745.74 | Special order, ships in 7-14 days |
| 7 | 88850600 | Ferrari LH BRACKET - 88850600 | $295.03 | Special order, ships in 7-14 days |
| 7 | 88850500 | Ferrari RH BRACKET - 88850500 | $295.03 | Special order, ships in 7-14 days |
