Ferrari Monza SP1 — [ELECTRICAL SYSTEM] - F.3 - INSTRUMENTATION (diagram 0178)
Exploded view of the [electrical system] - f.3 - instrumentation on the Ferrari Monza SP1, with 13 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Monza SP1 [ELECTRICAL SYSTEM] - F.3 - INSTRUMENTATION exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/monza-sp1/0178.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 81911200 | Ferrari Screw - 81911200 | Superseded | Order 85692200 instead | |
| 68176300 | Ferrari Screw 5x12 - 68176300 | Superseded | Order 85692200 instead | |
| 12638108 | Ferrari Washer - 12638108 | Superseded | Order 12638178 instead | |
| 12638177 | Ferrari Washer - 12638177 | Superseded | Order 12638178 instead | |
| 61276300 | Ferrari Washer - 61276300 | Superseded | Order 12638178 instead | |
| 1 | 829693 | Ferrari Quadro Strum Mta Ece Allum F - 829693 | $11,861.19 | Contact us to order |
| 1 | 829689 | Ferrari Quadro Strum Mta Ece Bianco - 829689 | $11,415.92 | Contact us to order |
| 1 | 829687 | Ferrari Quadro Strum Mta Ece Giallo - 829687 | $11,415.92 | Contact us to order |
| 1 | 829683 | Ferrari Quadro Strum Mta Ece Nero Cp - 829683 | $11,415.92 | Contact us to order |
| 1 | 829685 | Ferrari Quadro Strum Mta Ece Rosso C - 829685 | $11,415.92 | Contact us to order |
| 2 | 85692200 | Ferrari SCREW M5 x 12 - 85692200 | $0.65 | Available, ships in 3-6 days |
| 3 | 12638178 | Ferrari Washer 5.45-14x1 - 12638178 | $0.13 | Available, ships in 3-6 days |
| 4 | 85692300 | Ferrari Screw M5 x 20 TBFTX - 85692300 | $0.65 | Available, ships in 3-6 days |
