Ferrari Monza SP1 — [ELECTRICAL SYSTEM] - F.11 - ANTI-THEFT SYSTEM (diagram 0186)
Exploded view of the [electrical system] - f.11 - anti-theft system on the Ferrari Monza SP1, with 27 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Monza SP1 [ELECTRICAL SYSTEM] - F.11 - ANTI-THEFT SYSTEM exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/monza-sp1/0186.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 235627 | Ferrari ADR5 Satellite Anti-Theft System ECU - 235627 | Price on request | Contact us for price and availability | |
| 14039614 | Ferrari NUT - 14039614 | $0.40 | Available, ships in 3-6 days | |
| 277205 | Ferrari Satellite Anti-Theft System Ecu - 277205 | Superseded | Order 307603 instead | |
| 293779 | Ferrari Satellite Anti-Theft System Ecu - 293779 | $4,002.68 | Special order, ships in 7-14 days | |
| 11566224 | Ferrari Screw 5x14 - 11566224 | $0.77 | Available, ships in 3-6 days | |
| 1 | 293416 | Ferrari Master Dipole Anti-Lift Sensor - 293416 | $721.22 | Special order, ships in 7-14 days |
| 2 | 847642 | Ferrari Lower Bracket - Lift Sensor - 847642 | $151.74 | Special order, ships in 7-14 days |
| 3 | 847647 | Ferrari Upper Bracket - Lift Sensor - 847647 | $151.74 | Special order, ships in 7-14 days |
| 3 | 961651 | Ferrari Upper Bracket - Lift Sensor - 961651 | Superseded | Order 847647 instead |
| 4 | 330072 | Ferrari Compl. Anti-Theft System Sir - 330072 | $262.24 | Special order, ships in 7-14 days |
| 5 | 307603 | Ferrari ADR10 Satellite Anti-Theft System ECU - 307603 | $6,529.70 | Special order, ships in 7-14 days |
| 6 | 307605 | Ferrari ADR10 Satellite Alarm System Ecu - 307605 | $522.16 | Special order, ships in 7-14 days |
| 7 | 274465 | Ferrari GSM Antenna - 274465 | $80.48 | Special order, ships in 7-14 days |
| 8 | 274464 | Ferrari GPS Antenna - 274464 | $189.27 | Special order, ships in 7-14 days |
| 9 | 13579078 | Ferrari Washer - 13579078 | $0.44 | Special order, ships in 7-14 days |
| 10 | 14059111 | Ferrari Flanged Nut M5 - 14059111 | $0.08 | Available, ships in 3-6 days |
| 10 | 14039511 | Ferrari Nut - 14039511 | $0.54 | Available, ships in 3-6 days |
| 11 | 256323 | Ferrari Screw 5x16 - 256323 | $0.98 | Available, ships in 3-6 days |
| 12 | 931306346 | Ferrari Navtrack Fastener Bracket - 931306346 | Price on request | Contact us for price and availability |
| 13 | 63343400 | Ferrari Screw 4x15 - 63343400 | $5.02 | Available, ships in 3-6 days |
| 13 | 65752800 | Ferrari Screw M4 x 10 TBEI - 65752800 | $4.12 | Available, ships in 3-6 days |
| 14 | 85833700 | Ferrari SCREW - 85833700 | $0.65 | Available, ships in 3-6 days |
| 15 | 10794011 | Ferrari Nut M4 x 0.7mm - 10794011 | $0.06 | Available, ships in 3-6 days |
| 16 | 904234 | Ferrari Luggage Compartment Lid Rele - 904234 | $100.78 | Special order, ships in 7-14 days |
| 17 | 866260 | Ferrari Key And Block Kit - 866260 | $2,807.70 | Special order, ships in 7-14 days |
| 19 | 6326163 | Ferrari Secret Card Label For Keys - 6326163 | $4.39 | Special order, ships in 7-14 days |
| 20 | 307604 | Ferrari Adr Card Kit (Adr10) - 307604 | $5,333.79 | Special order, ships in 7-14 days |
