Ferrari Monza SP2 — [ENGINE] - B.5 - PISTONS AND CONNECTING RODS (diagram 0008)
Exploded view of the [engine] - b.5 - pistons and connecting rods on the Ferrari Monza SP2, with 20 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Monza SP2 [ENGINE] - B.5 - PISTONS AND CONNECTING RODS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/monza-sp2/0008.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 327386 | Ferrari Compl. Connecting Rod And Cap - 327386 | $490.90 | Special order, ships in 7-14 days | |
| 336530 | Ferrari Compl. Piston. LH Cylinder Bank - 336530 | Superseded | Order 55009100 instead | |
| 336529 | Ferrari Compl. Piston. RH Cylinder Bank - 336529 | Superseded | Order 55009099 instead | |
| 1 | 824391 | Ferrari Compl. Connecting Rod And Cap - 824391 | $493.10 | Special order, ships in 7-14 days |
| 2 | 281320 | Ferrari Con Rod Bolt - 281320 | $295.03 | Special order, ships in 7-14 days |
| 3 | 300758 | Ferrari Bushing - 300758 | $66.35 | Special order, ships in 7-14 days |
| 4 | 292751 | Ferrari Alignment Pin - 292751 | $44.24 | Special order, ships in 7-14 days |
| 5 | 55009099 | Ferrari Compl. Piston. RH Cylinder Bank - 55009099 | $2,013.87 | Special order, ships in 7-14 days |
| 5 | 803899 | Ferrari Compl. Piston. RH Cylinder Bank - 803899 | Superseded | Order 55009099 instead |
| 6 | 55009100 | Ferrari Compl. Piston. LH Cylinder Bank - 55009100 | $2,013.87 | Special order, ships in 7-14 days |
| 6 | 803900 | Ferrari Compl. Piston. LH Cylinder Bank - 803900 | Superseded | Order 55009100 instead |
| 7 | 304680 | Ferrari Con Rod Half-Bearing - 304680 | $31.93 | Special order, ships in 7-14 days |
| 7 | 304679 | Ferrari CONNECTING ROD HALF-BEARING - 304679 | Price on request | Contact us for price and availability |
| 7 | 304681 | Ferrari Connecting Rod Half-Bearing - 304681 | $34.40 | Special order, ships in 7-14 days |
| 7 | 304682 | Ferrari Connecting Rod Half-Bearing - 304682 | $34.40 | Special order, ships in 7-14 days |
| 7 | 304683 | Ferrari Connecting Rod Half-Bearing - 304683 | $34.40 | Special order, ships in 7-14 days |
| 7 | 823845 | Ferrari Connecting Rod Half-Bearing - 823845 | $31.93 | Special order, ships in 7-14 days |
| 7 | 823846 | Ferrari Connecting Rod Half-Bearing - 823846 | $31.93 | Special order, ships in 7-14 days |
| 8 | 55005635 | Ferrari Compl. Piston Ring Set - 55005635 | $590.08 | Special order, ships in 7-14 days |
| 8 | 863119 | Ferrari Piston Ring Set Complete - 863119 | $590.08 | Special order, ships in 7-14 days |
