Ferrari Monza SP2 — [ENGINE] - B.27 - ENGINE TEMPERATURE AND PRESSURE REGULATORS (diagram 0032)
Exploded view of the [engine] - b.27 - engine temperature and pressure regulators on the Ferrari Monza SP2, with 8 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Monza SP2 [ENGINE] - B.27 - ENGINE TEMPERATURE AND PRESSURE REGULATORS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/monza-sp2/0032.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 294902 | Ferrari Damped Mounting - 294902 | Superseded | Order 267300 instead | |
| 1 | 267849 | Ferrari Thermostat Compartment - 267849 | Superseded | Order 55057228 instead |
| 1 | 55057228 | Ferrari Thermostat Compartment - 55057228 | $1,253.96 | Special order, ships in 7-14 days |
| 2 | 180137 | Ferrari/Maserati Water Temperature Sender / Sensor - 180137 | $25.19 | In stock |
| 3 | 262913 | Ferrari Thermostat/Pressure Switch - 262913 | $371.08 | In stock |
| 4 | 228438 | Ferrari Connector - 228438 | $18.32 | Special order, ships in 7-14 days |
| 5 | 267300 | Ferrari Mount Bushing - 267300 | $13.18 | In stock |
| 6 | 304074 | Ferrari Oil Pressure Sending Unit - 304074 | $286.00 | In stock |
