Ferrari Monza SP2 — [MECHANICAL SYSTEM] - D.15 - EXPANSION TANK (diagram 0064)

Exploded view of the [mechanical system] - d.15 - expansion tank on the Ferrari Monza SP2, with 46 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari Monza SP2 [MECHANICAL SYSTEM] - D.15 - EXPANSION TANK exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
293146Ferrari Clip - 293146$2.09Special order, ships in 7-14 days
262112Ferrari Collar - 262112SupersededOrder 262111 instead
13046011Ferrari Flanged Nut - 13046011$0.73Available, ships in 3-6 days
14433121Ferrari Screw - 14433121SupersededOrder 231617 instead
216568Ferrari Screw 6x30 - 216568SupersededOrder 231621 instead
10860270Ferrari Screw Collar - 10860270$1.94Available, ships in 3-6 days
10860370Ferrari Screw Collar - 10860370$3.26Special order, ships in 7-14 days
13127770Ferrari Screw Collar - 13127770$2.82Special order, ships in 7-14 days
268210Ferrari Screw Collar - 268210$6.32Special order, ships in 7-14 days
12643711Ferrari Washer - 12643711SupersededOrder 12643724 instead
12643721Ferrari Washer - 12643721SupersededOrder 12643724 instead
14498804Ferrari Washer - 14498804SupersededOrder 14498824 instead
14499301Ferrari Washer - 14499301SupersededOrder 12643724 instead
1750859Ferrari Compl. Expansion Tank - 750859$233.56Special order, ships in 7-14 days
2145030Ferrari Radiator Cap - 145030$89.98In stock
3873407Ferrari Header Tank Drain Pipe - 873407$140.13Special order, ships in 7-14 days
4764686Ferrari Bracket - 764686$134.61Special order, ships in 7-14 days
585833900Ferrari Screw M5 x 16 TBFTX - 85833900$0.65Available, ships in 3-6 days
6262559Ferrari Clip - 262559$1.78Available, ships in 3-6 days
7231621Ferrari Allen Screw M6 x 30 TCEI - 231621$0.73Available, ships in 3-6 days
812640624Ferrari Plain Washer 6mm - 12640624$0.31Available, ships in 3-6 days
9286491Ferrari Spacer - 286491$66.35Special order, ships in 7-14 days
10286492Ferrari Cable Grommet - 286492$66.35Special order, ships in 7-14 days
11262111Ferrari Screw Collar - 262111$3.03Special order, ships in 7-14 days
12282575Ferrari Pipe From Reservoir To Disconnector Union - 282575$76.19Available, ships in 3-6 days
13262109Ferrari Screw Collar - 262109$2.01Available, ships in 3-6 days
14813272Ferrari Tubaz.Uscita Serb.Espansione - 813272$417.97Special order, ships in 7-14 days
15231617Ferrari Screw M6 x 18 TCEI - 231617SupersededOrder 14433124 instead
16288386Ferrari Rubber Pipe 7-14X107 - 288386$29.48Available, ships in 3-6 days
1713125470Ferrari Collar - 13125470SupersededOrder 13126970 instead
18879570Ferrari Tubazione Sfiati Rad.E Mo - 879570$611.91Special order, ships in 7-14 days
18937578Ferrari Tubazione Sfiati Rad.E Mo - 937578$611.91Special order, ships in 7-14 days
19212519Ferrari Stud Bolt - 212519$12.29Special order, ships in 7-14 days
2014040514Ferrari Flanged Nut - 14040514SupersededOrder 13046011 instead
21879792Ferrari Tubo Gomma D. 7-14 Preforma - 879792$44.03Special order, ships in 7-14 days
22288385Ferrari Rubber Pipe D. 7-14X235 - 288385$36.86Available, ships in 3-6 days
23281899Ferrari 3 Way Union With Bracket Complete - 281899$6.31Special order, ships in 7-14 days
24342162Ferrari Pipe - 342162$93.40Special order, ships in 7-14 days
2513000290Ferrari Clamp D. 12 - 18 x 7 - 13000290$1.74Available, ships in 3-6 days
26339343Ferrari Clip - 339343$5.65Special order, ships in 7-14 days
27340329Ferrari Rubber Pipe - 340329$90.95Special order, ships in 7-14 days
28257273Ferrari Clip D. 14-16 - 257273$2.59Special order, ships in 7-14 days
29103549Ferrari Grommet - 103549$2.80In stock
30149707Ferrari Spacer - 149707$2.13Available, ships in 3-6 days
3162766300Ferrari Spire Clip M6 - 62766300$1.36Available, ships in 3-6 days
3212643724Ferrari/Maserati Washer - 12643724$0.20In stock
