Ferrari Monza SP2 — [MECHANICAL SYSTEM] - D.37 - PLATES (diagram 0092)
Exploded view of the [mechanical system] - d.37 - plates on the Ferrari Monza SP2, with 26 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Monza SP2 [MECHANICAL SYSTEM] - D.37 - PLATES exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/monza-sp2/0092.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 255167 | Ferrari Engine Oil Check Label - 255167 | Superseded | Order 262089 instead | |
| 258126 | Ferrari Engine Oil Check Label - 258126 | Superseded | Order 262089 instead | |
| 250436 | Ferrari Engine/Gearbox Oil Adhesive Label - 250436 | Superseded | Order 258125 instead | |
| 234909 | Ferrari Oil Level Check Plate - 234909 | $13.93 | Special order, ships in 7-14 days | |
| 269475 | Ferrari Polyester S&S Warning Label - 269475 | Superseded | Order 281805 instead | |
| 295138 | Ferrari Polyester S&S Warning Label - 295138 | $22.50 | Special order, ships in 7-14 days | |
| 269267 | Ferrari S&S Warning Label - 269267 | Superseded | Order 281806 instead | |
| 295139 | Ferrari S&S Warning Label - 295139 | Superseded | Order 281806 instead | |
| 1 | 829199 | Ferrari 'Fuels' Label - 829199 | $5.14 | Special order, ships in 7-14 days |
| 1 | 12858780 | Ferrari Adhesive Unleaded Petrol/Gasoline Label - 12858780 | $6.11 | Special order, ships in 7-14 days |
| 2 | 304914 | Ferrari Filling Procedure Instruction Label - 304914 | $14.47 | Special order, ships in 7-14 days |
| 3 | 297529 | Ferrari Radiator Contains Antifreeze Label - 297529 | $11.35 | Available, ships in 3-6 days |
| 4 | 160889 | Ferrari Brake Fluid Reservoir Label - 160889 | $5.39 | Available, ships in 3-6 days |
| 5 | 293457 | Ferrari Max Speed With Winter Tyres Label - 293457 | $29.48 | Special order, ships in 7-14 days |
| 6 | 194621 | Ferrari Tyre Pressure Warning Label - 194621 | $36.86 | Special order, ships in 7-14 days |
| 7 | 861276 | Ferrari Targhetta Pressione Pneum. P - 861276 | $56.27 | Special order, ships in 7-14 days |
| 8 | 281805 | Ferrari Polyester S&S Warning Label - 281805 | $27.82 | Available, ships in 3-6 days |
| 9 | 281806 | Ferrari S&S Warning Label - 281806 | $51.62 | Special order, ships in 7-14 days |
| 10 | 262089 | Ferrari Oil Level Check Plate - 262089 | $20.56 | Available, ships in 3-6 days |
| 11 | 258125 | Ferrari Engine/Gearbox Oil Specifications Label - 258125 | $12.77 | Special order, ships in 7-14 days |
| 12 | 55046739 | Ferrari Label For Vehicle With Air C - 55046739 | $15.72 | Special order, ships in 7-14 days |
| 12 | 783963 | Ferrari Label For Vehicle With Air C - 783963 | Superseded | Order 55046739 instead |
| 13 | 279667 | Ferrari High Voltage Warning Label - 279667 | $24.55 | Special order, ships in 7-14 days |
| 14 | 180092 | Ferrari Low Beam Approval Label - 180092 | $1.84 | Available, ships in 3-6 days |
| 15 | 872489 | Ferrari Targhetta Warning Apertura C - 872489 | $56.27 | Special order, ships in 7-14 days |
| 16 | 950533 | Ferrari Targ. Veci Label "50S" Map M - 950533 | $61.16 | Special order, ships in 7-14 days |
