Ferrari Monza SP2 — [VEHICLE TRIM] - E.8 - FRONT DOOR SUBSTRUCTURE (diagram 0104)
Exploded view of the [vehicle trim] - e.8 - front door substructure on the Ferrari Monza SP2, with 13 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Monza SP2 [VEHICLE TRIM] - E.8 - FRONT DOOR SUBSTRUCTURE exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/monza-sp2/0104.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 985881730 | Ferrari RH Front Door - 985881730 | $79,104.39 | Contact us to order |
| 2 | 985881688 | Ferrari LH Front Door - 985881688 | $79,104.39 | Contact us to order |
| 3 | 867575 | Ferrari Compl. RH Door Hinge - 867575 | $6,338.54 | Special order, ships in 7-14 days |
| 4 | 867574 | Ferrari Compl. LH Door Hinge - 867574 | $6,338.54 | Special order, ships in 7-14 days |
| 5 | 85849200 | Ferrari Plate - 85849200 | $22.25 | Special order, ships in 7-14 days |
| 6 | 85429700 | Ferrari Plate - 85429700 | $44.03 | Special order, ships in 7-14 days |
| 7 | 296945 | Ferrari Screw - 296945 | $4.33 | Special order, ships in 7-14 days |
| 8 | 284148 | Ferrari Washer - 284148 | $1.48 | Special order, ships in 7-14 days |
| 9 | 296763 | Ferrari Washer - 296763 | $2.01 | Special order, ships in 7-14 days |
| 10 | 893581 | Ferrari Screw M8 x 25 - 893581 | $1.48 | Special order, ships in 7-14 days |
| 11 | 894634 | Ferrari Washer - 894634 | $0.86 | Special order, ships in 7-14 days |
| 12 | 952842 | Ferrari Flat Washer D. 8.15-25X - 952842 | $0.92 | Special order, ships in 7-14 days |
| 12 | 86150100 | Ferrari Washer - 86150100 | $1.80 | Special order, ships in 7-14 days |
