Ferrari Monza SP2 — [VEHICLE TRIM] - E.9 - FRONT LID SUBSTRUCTURE (diagram 0105)
Exploded view of the [vehicle trim] - e.9 - front lid substructure on the Ferrari Monza SP2, with 14 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Monza SP2 [VEHICLE TRIM] - E.9 - FRONT LID SUBSTRUCTURE exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/monza-sp2/0105.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 881828 | Ferrari Front Lid - 881828 | Superseded | Order 985787152 instead |
| 1 | 881851 | Ferrari Front Lid - 881851 | Superseded | Order 985787151 instead |
| 1 | 985787151 | Ferrari Front Lid - 985787151 | $205,488.29 | Contact us to order |
| 1 | 985787152 | Ferrari Front Lid - 985787152 | $205,488.29 | Contact us to order |
| 2 | 874465 | Ferrari Cerniera-Cofano-Ant-Cpl-Dx - 874465 | $1,841.62 | Contact us to order |
| 3 | 874464 | Ferrari Cerniera-Cofano-Ant-Cpl-Sx - 874464 | $1,841.62 | Contact us to order |
| 4 | 296945 | Ferrari Screw - 296945 | $4.33 | Special order, ships in 7-14 days |
| 5 | 296763 | Ferrari Washer - 296763 | $2.01 | Special order, ships in 7-14 days |
| 6 | 860507 | Ferrari Shim - 860507 | $39.14 | Special order, ships in 7-14 days |
| 7 | 893581 | Ferrari Screw M8 x 25 - 893581 | $1.48 | Special order, ships in 7-14 days |
| 8 | 894634 | Ferrari Washer - 894634 | $0.86 | Special order, ships in 7-14 days |
| 9 | 86150100 | Ferrari Washer - 86150100 | $1.80 | Special order, ships in 7-14 days |
| 10 | 893650 | Ferrari Nut - 893650 | $5.65 | Special order, ships in 7-14 days |
| 13 | 952842 | Ferrari Flat Washer D. 8.15-25X - 952842 | $0.92 | Special order, ships in 7-14 days |
