Ferrari Monza SP2 — [VEHICLE TRIM] - E.19 - INTERNAL CABIN INSULATION (diagram 0118)
Exploded view of the [vehicle trim] - e.19 - internal cabin insulation on the Ferrari Monza SP2, with 7 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Monza SP2 [VEHICLE TRIM] - E.19 - INTERNAL CABIN INSULATION exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/monza-sp2/0118.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 854968 | Ferrari Isolante Parafiamma - 854968 | $465.04 | Special order, ships in 7-14 days |
| 2 | 82298500 | Ferrari Driver Side Footrest Insulation LHD - 82298500 | $93.40 | Special order, ships in 7-14 days |
| 3 | 82298600 | Ferrari Passenger Side Footrest Insulation LHD - 82298600 | $100.78 | Special order, ships in 7-14 days |
| 4 | 892720 | Ferrari Riparo Calore Posteriore Sot - 892720 | $127.27 | Special order, ships in 7-14 days |
| 5 | 67315400 | Ferrari Washer - 67315400 | $0.82 | Special order, ships in 7-14 days |
| 6 | 84929500 | Ferrari Upper Front Centre Tunnel Insulation - 84929500 | $83.57 | Special order, ships in 7-14 days |
| 7 | 892725 | Ferrari Riparo Calore Anteriore Sott - 892725 | $127.27 | Special order, ships in 7-14 days |
