Ferrari Monza SP2 — [VEHICLE TRIM] - E.47.05 - DASHBOARD - DUCTS -Not for RHD- (diagram 0153)
Exploded view of the [vehicle trim] - e.47.05 - dashboard - ducts -not for rhd- on the Ferrari Monza SP2, with 7 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Monza SP2 [VEHICLE TRIM] - E.47.05 - DASHBOARD - DUCTS -Not for RHD- exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/monza-sp2/0153.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 831513 | Ferrari Condotto Aria Bocchetta Late - 831513 | $1,737.90 | Special order, ships in 7-14 days |
| 2 | 831514 | Ferrari Condotto Aria Bocch Laterale - 831514 | $2,098.07 | Special order, ships in 7-14 days |
| 3 | 84088300 | Ferrari Passenger Side Upper Footwell Air Duct LHD - 84088300 | $115.54 | Special order, ships in 7-14 days |
| 4 | 87891900 | Ferrari Driver Side Footwell Air Duc - 87891900 | $295.03 | Special order, ships in 7-14 days |
| 5 | 88390600 | Ferrari Passenger Side Lower Footwel - 88390600 | $86.04 | Special order, ships in 7-14 days |
| 6 | 87893300 | Ferrari Compl. LH HVAC Ventilation System Connector - 87893300 | $174.55 | Special order, ships in 7-14 days |
| 7 | 831511 | Ferrari Condotto Aria Centrale Cpl - 831511 | $1,517.60 | Special order, ships in 7-14 days |
