Ferrari Monza SP2 — [VEHICLE TRIM] - E.49 - INNER TRIM (ABOVE BELTLINE) (diagram 0159)
Exploded view of the [vehicle trim] - e.49 - inner trim (above beltline) on the Ferrari Monza SP2, with 35 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Monza SP2 [VEHICLE TRIM] - E.49 - INNER TRIM (ABOVE BELTLINE) exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/monza-sp2/0159.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 892670 | Ferrari Puler - 892670 | $6.57 | Special order, ships in 7-14 days | |
| 81911200 | Ferrari Screw - 81911200 | Superseded | Order 85692200 instead | |
| 68176300 | Ferrari Screw 5x12 - 68176300 | Superseded | Order 85692200 instead | |
| 11566224 | Ferrari Screw 5x14 - 11566224 | $0.77 | Available, ships in 3-6 days | |
| 12638108 | Ferrari Washer - 12638108 | Superseded | Order 12638178 instead | |
| 12638177 | Ferrari Washer - 12638177 | Superseded | Order 12638178 instead | |
| 61276300 | Ferrari Washer - 61276300 | Superseded | Order 12638178 instead | |
| 86211600 | Ferrari Washer - 86211600 | Superseded | Order 65545900 instead | |
| 1 | 881750 | Ferrari RH Sill Trim - 881750 | $15,572.48 | Contact us to order |
| 2 | 881749 | Ferrari LH Sill Trim - 881749 | $15,572.48 | Contact us to order |
| 3 | 834113 | Ferrari RH Front Shield - 834113 | $4,310.38 | Special order, ships in 7-14 days |
| 4 | 834111 | Ferrari LH Front Shield - 834111 | $4,310.38 | Special order, ships in 7-14 days |
| 5 | 890352 | Ferrari Compl. RH Armrest - 890352 | $783.26 | Special order, ships in 7-14 days |
| 5 | 906492 | Ferrari Compl. RH Armrest - 906492 | $636.39 | Special order, ships in 7-14 days |
| 6 | 890353 | Ferrari Compl. LH Armrest - 890353 | $1,321.77 | Special order, ships in 7-14 days |
| 6 | 906489 | Ferrari Compl. LH Armrest - 906489 | $636.39 | Special order, ships in 7-14 days |
| 7 | 85692000 | Ferrari SCREW - 85692000 | $0.65 | Available, ships in 3-6 days |
| 7 | 85833700 | Ferrari SCREW - 85833700 | $0.65 | Available, ships in 3-6 days |
| 8 | 65545900 | Ferrari Black Plastic Washer - 65545900 | $6.32 | Special order, ships in 7-14 days |
| 8 | 12638178 | Ferrari Washer 5.45-14x1 - 12638178 | $0.13 | Available, ships in 3-6 days |
| 9 | 85692300 | Ferrari Screw M5 x 20 TBFTX - 85692300 | $0.65 | Available, ships in 3-6 days |
| 10 | 85692200 | Ferrari SCREW M5 x 12 - 85692200 | $0.65 | Available, ships in 3-6 days |
| 10 | 86705000 | Ferrari Screw M5x10 TBFTX - 86705000 | $1.36 | Special order, ships in 7-14 days |
| 11 | 67278400 | Ferrari BRACKET - 67278400 | $21.60 | Special order, ships in 7-14 days |
| 12 | 68700200 | Ferrari Fixing Clip - 68700200 | $10.68 | Special order, ships in 7-14 days |
| 13 | 82672700 | Ferrari Fixing Clip - 82672700 | $1.67 | Available, ships in 3-6 days |
| 14 | 836387 | Ferrari Compl. RH Midrange Speaker G - 836387 | $342.66 | Special order, ships in 7-14 days |
| 15 | 836390 | Ferrari Compl. LH Midrange Speaker G - 836390 | $342.66 | Special order, ships in 7-14 days |
| 16 | 842731 | Ferrari Compl. RH Midrange Speaker Bracket - 842731 | $93.00 | Special order, ships in 7-14 days |
| 17 | 842746 | Ferrari Compl. LH Midrange Speaker Bracket - 842746 | $93.00 | Special order, ships in 7-14 days |
| 18 | 10794011 | Ferrari Nut M4 x 0.7mm - 10794011 | $0.06 | Available, ships in 3-6 days |
| 19 | 836388 | Ferrari LH Tweeter Grille - 836388 | $88.09 | Special order, ships in 7-14 days |
| 20 | 13046014 | Ferrari Nut - 13046014 | $0.63 | Special order, ships in 7-14 days |
| 21 | 922720 | Ferrari Puler - 922720 | $26.89 | Special order, ships in 7-14 days |
| 22 | 959360 | Ferrari RH Passenger Compartment Mats Membrane - 959360 | $56.27 | Special order, ships in 7-14 days |
