Ferrari Monza SP2 — [VEHICLE TRIM] - E.50 - OTHER INTERIOR TRIM ELEMENTS (diagram 0160)
Exploded view of the [vehicle trim] - e.50 - other interior trim elements on the Ferrari Monza SP2, with 10 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Monza SP2 [VEHICLE TRIM] - E.50 - OTHER INTERIOR TRIM ELEMENTS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/monza-sp2/0160.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 3 | 88527400 | Ferrari Lower Steering Column Trim B - 88527400 | $565.49 | Special order, ships in 7-14 days |
| 4 | 86431600 | Ferrari Bracket On Lower Steering Column - 86431600 | $23.08 | Special order, ships in 7-14 days |
| 5 | 14304224 | Ferrari Screw M5 x 16 - 14304224 | $0.27 | Available, ships in 3-6 days |
| 6 | 14059121 | Ferrari Nut M5 - 14059121 | $0.31 | Available, ships in 3-6 days |
| 7 | 63343400 | Ferrari Screw 4x15 - 63343400 | $5.02 | Available, ships in 3-6 days |
| 7 | 15688801 | Ferrari Screw M3.5 x 13 - 15688801 | Superseded | Order 63343400 instead |
| 8 | 68002000 | Ferrari Rubber Pad - 68002000 | $7.40 | Special order, ships in 7-14 days |
| 9 | 15689201 | Ferrari Screw M3.5 x 25 - 15689201 | $1.92 | Available, ships in 3-6 days |
| 10 | 88490300 | Ferrari Engine Button Mounting Brack - 88490300 | $66.35 | Special order, ships in 7-14 days |
| 11 | 65752800 | Ferrari Screw M4 x 10 TBEI - 65752800 | $4.12 | Available, ships in 3-6 days |
