Ferrari Monza SP2 — [ELECTRICAL SYSTEM] - F.16 - ADAS AND SENSORS (diagram 0191)
Exploded view of the [electrical system] - f.16 - adas and sensors on the Ferrari Monza SP2, with 11 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Monza SP2 [ELECTRICAL SYSTEM] - F.16 - ADAS AND SENSORS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/monza-sp2/0191.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 839804 | Ferrari Parking Camera ECU - 839804 | $3,254.35 | Special order, ships in 7-14 days |
| 2 | 195646 | Ferrari Clip - 195646 | $2.82 | Available, ships in 3-6 days |
| 3 | 263079 | Ferrari Accelerator For Magneride System - 263079 | Superseded | Order 990305 instead |
| 3 | 990305 | Ferrari Accelerator For Magneride System - 990305 | $442.56 | Available, ships in 3-6 days |
| 4 | 314815 | Ferrari Tpms ECU Antenna - 314815 | $983.50 | Special order, ships in 7-14 days |
| 5 | 764924 | Ferrari LATERAL CRASH SENSOR - 764924 | $74.29 | Special order, ships in 7-14 days |
| 6 | 904661 | Ferrari Sunlight. Fogging And Rain S - 904661 | $2,436.87 | Special order, ships in 7-14 days |
| 7 | 764923 | Ferrari Front Crash Sensor - 764923 | $74.29 | Available, ships in 3-6 days |
| 8 | 14303024 | Ferrari Allen Screw M4 x 12 TCEI - 14303024 | $1.63 | Available, ships in 3-6 days |
| 9 | 330828 | Ferrari Parking Camera ECU Protectiv - 330828 | $112.57 | Special order, ships in 7-14 days |
| 10 | 85692000 | Ferrari SCREW - 85692000 | $0.65 | Available, ships in 3-6 days |
