Ferrari Portofino M — [GENERAL] - A.1 - SPARE ASSEMBLY UNITS (diagram 0001)
Exploded view of the [general] - a.1 - spare assembly units on the Ferrari Portofino M, with 6 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Portofino M [GENERAL] - A.1 - SPARE ASSEMBLY UNITS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/portofino-m/0001.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 796044 | Ferrari Set Of Engine Gaskets - 796044 | $2,157.38 | Special order, ships in 7-14 days |
| 2 | 985000347 | Ferrari Short Block - 985000347 | $49,372.14 | Contact us to order |
| 3 | 763129 | Ferrari Complete Gearbox - 763129 | $68,982.02 | Contact us to order |
| 3 | 847403 | Ferrari Complete Gearbox - 847403 | Superseded | Order 763129 instead |
| 3 | 985352 | Ferrari Complete Gearbox - 985352 | Superseded | Order 763129 instead |
| 4 | 873159 | Ferrari Short Block Gasket Kit - 873159 | $344.69 | Special order, ships in 7-14 days |
