Ferrari Portofino M — [ENGINE] - B.19 - VACUUM PUMP (diagram 0024)
Exploded view of the [engine] - b.19 - vacuum pump on the Ferrari Portofino M, with 5 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Portofino M [ENGINE] - B.19 - VACUUM PUMP exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/portofino-m/0024.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 834367 | Ferrari Screw 8x25 - 834367 | Superseded | Order 231628 instead | |
| 1 | 341928 | Ferrari Depressore Bosch - 341928 | $1,181.86 | Special order, ships in 7-14 days |
| 2 | 333545 | Ferrari Coperchio Per Sede Depresso - 333545 | $150.17 | Special order, ships in 7-14 days |
| 3 | 335257 | Ferrari Gasket - 335257 | $29.52 | Special order, ships in 7-14 days |
| 4 | 231628 | Ferrari Screw 8x25 - 231628 | $1.15 | Special order, ships in 7-14 days |
