Ferrari Portofino M — [MECHANICAL SYSTEM] - D.04.02 - INTERCOOLER (diagram 0052)

Exploded view of the [mechanical system] - d.04.02 - intercooler on the Ferrari Portofino M, with 69 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari Portofino M [MECHANICAL SYSTEM] - D.04.02 - INTERCOOLER exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
293146Ferrari Clip - 293146$2.09Special order, ships in 7-14 days
206536Ferrari Clip D.14 - 206536$0.92Special order, ships in 7-14 days
297575Ferrari Collar - 297575SupersededOrder 311609 instead
14433121Ferrari Screw - 14433121SupersededOrder 231617 instead
876093Ferrari Tubo Ingresso Compressore Dx - 876093SupersededOrder 769698 instead
876094Ferrari Tubo Ingresso Compressore Sx - 876094SupersededOrder 769699 instead
1340705Ferrari LH Intercooler - 340705$1,255.72Special order, ships in 7-14 days
1340704Ferrari RH Intercooler - 340704$1,255.72Special order, ships in 7-14 days
2780895Ferrari Collar - 780895$7.63Available, ships in 3-6 days
3327937Ferrari Manicotto Uscita Intercooler - 327937$219.11Special order, ships in 7-14 days
3327938Ferrari Manicotto Uscita Intercooler - 327938$219.11Special order, ships in 7-14 days
4786970Ferrari Intermediate Pipe Between Intercooler and Intake - 786970$98.46Special order, ships in 7-14 days
5272880Ferrari Pressure and Temperature Sensor - 272880$61.26Available, ships in 3-6 days
6231617Ferrari Screw M6 x 18 TCEI - 231617SupersededOrder 14433124 instead
7311609Ferrari Collar - 311609$6.10Special order, ships in 7-14 days
8332709Ferrari Compl. LH Throttle Body Coll - 332709$393.93Special order, ships in 7-14 days
8332708Ferrari Compl. RH Throttle Body Coll - 332708$393.93Special order, ships in 7-14 days
9747660Ferrari Tubo Lav. Da Asp. A Venturi - 747660$145.25Special order, ships in 7-14 days
9747661Ferrari Tubo Lav. Da Asp. A Venturi - 747661$145.25Special order, ships in 7-14 days
10782582Ferrari Bush - Intercooler Support - 782582$7.86Special order, ships in 7-14 days
11338492Ferrari Spacer - 338492$10.25Special order, ships in 7-14 days
12290938Ferrari Intercooler Fastener Rubber Bush - 290938$16.96Special order, ships in 7-14 days
1366121400Ferrari Spacer - 66121400$20.34Available, ships in 3-6 days
14332707Ferrari Manicot. Ingresso Intercoole - 332707$177.25Special order, ships in 7-14 days
15297483Ferrari Double Elastic Collar - 297483$11.35Available, ships in 3-6 days
16339352Ferrari LH Pipe From Engine To Inter - 339352$320.06Special order, ships in 7-14 days
16339351Ferrari RH Pipe From Engine To Intercooler - 339351$320.06Available, ships in 3-6 days
17285553Ferrari Vibration Damper - 285553$36.00In stock
1812647604Ferrari Washer - 12647604$0.12Available, ships in 3-6 days
1914040614Ferrari Flanged Nut 6mm - 14040614$0.27Available, ships in 3-6 days
20813624Ferrari Manicotto Da Turbo Ad Interc - 813624$115.69Special order, ships in 7-14 days
21813619Ferrari Tubo Flangiato Uscita Comp. - 813619$418.56Special order, ships in 7-14 days
21813620Ferrari Tubo Flangiato Uscita Comp. - 813620$443.17Special order, ships in 7-14 days
22323665Ferrari Allen Head Bolt with Washer M6X14 - 323665$0.63Special order, ships in 7-14 days
23308862Ferrari Compressor Outlet Gasket - 308862$34.44Special order, ships in 7-14 days
24231620Ferrari/Maserati Screw - 231620$0.58In stock
2513001190Ferrari Clamp 80-100mm - 13001190$2.07Available, ships in 3-6 days
26340923Ferrari Manicotto Condotto Aspirazio - 340923$123.09Special order, ships in 7-14 days
26340924Ferrari Manicotto Condotto Aspirazio - 340924$123.09Special order, ships in 7-14 days
27323688Ferrari Ring Clamp - 323688$8.93Special order, ships in 7-14 days
28945330Ferrari Compl RH Ancillaries Pipe with Bracket - 945330$369.30Special order, ships in 7-14 days
28342016Ferrari Compl. LH Ancillaries Pipe - 342016$236.34Special order, ships in 7-14 days
28843953Ferrari Complete LH Ancillaries Pipe - 843953$243.74Special order, ships in 7-14 days
28875742Ferrari Complete RH Ancillaries Pipe - 875742$295.43Special order, ships in 7-14 days
29257273Ferrari Clip D. 14-16 - 257273$2.59Special order, ships in 7-14 days
30328198Ferrari Manicotto Condotto Ingresso - 328198$295.43Special order, ships in 7-14 days
30974284Ferrari Turbo Inlet Duct Hose - 974284$219.11Special order, ships in 7-14 days
31308759Ferrari Collar - 308759$7.19Special order, ships in 7-14 days
32769699Ferrari LH Compressor Inlet Pipe - 769699$169.87Special order, ships in 7-14 days
32769698Ferrari RH Compressor Inlet Pipe - 769698$169.87Special order, ships in 7-14 days
33330933Ferrari Compressor Intake Gasket - 330933$35.00Special order, ships in 7-14 days
34898692Ferrari Compl. LH Pipe - 898692$517.04Special order, ships in 7-14 days
34875746Ferrari Tubo Lav.Dx Da Mot.Ad Asp.Cp - 875746$418.56Special order, ships in 7-14 days
34875747Ferrari Tubo Lav.Sx Da Mot.Ad Asp. C - 875747$418.56Special order, ships in 7-14 days
35233600Ferrari/Maserati Screw - 233600$1.98In stock
36828057Ferrari Compl. Flush Pipe Bracket - 828057$110.78Special order, ships in 7-14 days
37198253Ferrari Clip - 198253$7.40Special order, ships in 7-14 days
38897379Ferrari Rubber Bushing - 897379$18.42Special order, ships in 7-14 days
38195373Ferrari Rubber Support Pad - 195373$29.48Available, ships in 3-6 days
3986705100Ferrari Clip - 86705100$4.77Special order, ships in 7-14 days
40878602Ferrari Compl. LH Pipe - Valv.Tev5 - 878602$517.04Special order, ships in 7-14 days
40878601Ferrari Compl. RH Pipe - Valv.Tev5 - 878601$615.54Special order, ships in 7-14 days
41303697Ferrari Bracket - Pipe Support - 303697$64.00Special order, ships in 7-14 days
42329520Ferrari Bracket - Pipe Support - 329520$29.52Special order, ships in 7-14 days
43253512Ferrari Bracket With Sheath - 253512$16.83Special order, ships in 7-14 days
44878603Ferrari Complete Bracket - 878603$56.60Special order, ships in 7-14 days
45340995Ferrari Flush Valve Mounting Bracket - 340995$76.30Special order, ships in 7-14 days
46949011Ferrari Blow-By Pipe Mounting Bracke - 949011$39.37Special order, ships in 7-14 days
47304443Ferrari Clip - 304443$1.36Special order, ships in 7-14 days
