Ferrari Portofino M — [MECHANICAL SYSTEM] - D.21 - SERVO BRAKE PIPES (diagram 0070)
Exploded view of the [mechanical system] - d.21 - servo brake pipes on the Ferrari Portofino M, with 5 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Portofino M [MECHANICAL SYSTEM] - D.21 - SERVO BRAKE PIPES exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/portofino-m/0070.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 756995 | Ferrari Brake Servo Vacuum Pipe - 756995 | $295.43 | Special order, ships in 7-14 days |
| 1 | 741001 | Ferrari Tubaz.Depress.Servofreno S & - 741001 | $270.83 | Special order, ships in 7-14 days |
| 2 | 81840800 | Ferrari Clip - 81840800 | $0.79 | Special order, ships in 7-14 days |
| 3 | 250318 | Ferrari Clip - 250318 | $0.50 | Special order, ships in 7-14 days |
| 3 | 82396800 | Ferrari Clip - 82396800 | $2.01 | Special order, ships in 7-14 days |
