Ferrari Portofino M — [MECHANICAL SYSTEM] - D.37 - PLATES (diagram 0092)

Exploded view of the [mechanical system] - d.37 - plates on the Ferrari Portofino M, with 54 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari Portofino M [MECHANICAL SYSTEM] - D.37 - PLATES exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
255167Ferrari Engine Oil Check Label - 255167SupersededOrder 262089 instead
256569Ferrari Engine Oil Check Label - 256569SupersededOrder 262090 instead
258126Ferrari Engine Oil Check Label - 258126SupersededOrder 262089 instead
234909Ferrari Oil Level Check Plate - 234909$13.93Special order, ships in 7-14 days
245897Ferrari Oil Level Check Plate - 245897SupersededOrder 262090 instead
269475Ferrari Polyester S&S Warning Label - 269475SupersededOrder 281805 instead
295138Ferrari Polyester S&S Warning Label - 295138$22.50Special order, ships in 7-14 days
269267Ferrari S&S Warning Label - 269267SupersededOrder 281806 instead
295139Ferrari S&S Warning Label - 295139SupersededOrder 281806 instead
1258127Ferrari GlycoShell Radiator Antifreeze Label - 258127$11.85In stock
1297529Ferrari Radiator Contains Antifreeze Label - 297529$11.35Available, ships in 3-6 days
1305631Ferrari Radiator Contains Antifreeze Label - 305631$63.90Special order, ships in 7-14 days
2281805Ferrari Polyester S&S Warning Label - 281805$27.82Available, ships in 3-6 days
2305633Ferrari Polyester S&S Warning Label - 305633$159.79Special order, ships in 7-14 days
3279667Ferrari High Voltage Warning Label - 279667$24.55Special order, ships in 7-14 days
3284515Ferrari High Voltage Warning Label - 284515$115.54Special order, ships in 7-14 days
3306544Ferrari High Voltage Warning Label - 306544$15.98Special order, ships in 7-14 days
4262089Ferrari Oil Level Check Plate - 262089$20.56Available, ships in 3-6 days
4262090Ferrari Oil Level Check Plate - 262090$120.46Special order, ships in 7-14 days
4306543Ferrari Oil Level Check Plate - 306543$213.88Special order, ships in 7-14 days
5281806Ferrari S&S Warning Label - 281806$51.62Special order, ships in 7-14 days
5305634Ferrari S&S Warning Label - 305634$149.96Special order, ships in 7-14 days
6194621Ferrari Tyre Pressure Warning Label - 194621$36.86Special order, ships in 7-14 days
6218182Ferrari Tyre Pressure Warning Label - 218182$110.61Special order, ships in 7-14 days
6305632Ferrari Tyre Pressure Warning Label - 305632$49.14Special order, ships in 7-14 days
7293457Ferrari Max Speed With Winter Tyres Label - 293457$29.48Special order, ships in 7-14 days
7305630Ferrari Max Speed With Winter Tyres Label - 305630$78.66Special order, ships in 7-14 days
8304914Ferrari Filling Procedure Instruction Label - 304914$14.47Special order, ships in 7-14 days
8308904Ferrari Filling Procedure Instruction Label - 308904Price on requestContact us for price and availability
8308953Ferrari Filling Procedure Instruction Label - 308953$58.98Special order, ships in 7-14 days
9829199Ferrari 'Fuels' Label - 829199$5.14Special order, ships in 7-14 days
912858780Ferrari Adhesive Unleaded Petrol/Gasoline Label - 12858780$6.11Special order, ships in 7-14 days
10160889Ferrari Brake Fluid Reservoir Label - 160889$5.39Available, ships in 3-6 days
10980009Ferrari Targh. Adesiva Avvertenze Ol - 980009$20.62Special order, ships in 7-14 days
11884586Ferrari Tyre Pressure Label 20 Tyre - 884586$24.59Special order, ships in 7-14 days
11903225Ferrari Tyre Pressure Label Bridges - 903225$130.47Special order, ships in 7-14 days
11742778Ferrari Tyre Pressure Label Pirelli - 742778SupersededOrder 884584 instead
11884573Ferrari Tyre Pressure Label Pirelli - 884573$44.29Special order, ships in 7-14 days
11884584Ferrari Tyre Pressure Label Pirelli - 884584$11.31Special order, ships in 7-14 days
11903222Ferrari Tyre Pressure Label Pirelli - 903222$44.29Special order, ships in 7-14 days
12180092Ferrari Low Beam Approval Label - 180092$1.84Available, ships in 3-6 days
1355046736Ferrari Targhetta Sae Gas Refrig. - 55046736$16.71Special order, ships in 7-14 days
13790530Ferrari Targhetta Sae Gas Refrig. - 790530$44.29Special order, ships in 7-14 days
14924199Ferrari Adhesive Label Specifying En - 924199$29.48Special order, ships in 7-14 days
14924201Ferrari Engine/Gearbox Oil Specification Label - 924201$12.52Special order, ships in 7-14 days
14924200Ferrari ENGINE/GEARBOX OIL SPECIFICATIONS LABEL - 924200Price on requestContact us for price and availability
16334592Ferrari Mercury Content Label - 334592Price on requestContact us for price and availability
17255003Ferrari Radiator Label - 255003$41.76Special order, ships in 7-14 days
1868960300Ferrari Driver Side Rear View Mirror label - 68960300$51.62Special order, ships in 7-14 days
19768347Ferrari Fuel Indication Label - 768347$21.60Special order, ships in 7-14 days
20294454Ferrari Air Con System Label - 294454$49.14Special order, ships in 7-14 days
21872693Ferrari 50S Engine Map Label - 872693$13.01Special order, ships in 7-14 days
21948023Ferrari 50S Engine Map Label - 948023Price on requestContact us for price and availability
22777850Ferrari Eac Label - 777850$49.22Special order, ships in 7-14 days
