Ferrari Portofino M — [VEHICLE TRIM] - E.12 - ROLLBAR (diagram 0108)
Exploded view of the [vehicle trim] - e.12 - rollbar on the Ferrari Portofino M, with 12 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Portofino M [VEHICLE TRIM] - E.12 - ROLLBAR exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/portofino-m/0108.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 16043430 | Ferrari Bolt - 16043430 | Superseded | Order 16043434 instead | |
| 16043431 | Ferrari Screw - 16043431 | Superseded | Order 16043434 instead | |
| 124338 | Ferrari Washer D. 8 - 25 x 3 - 124338 | $14.55 | Available, ships in 3-6 days | |
| 1 | 69905000 | Ferrari Active Roll Bar - 69905000 | Superseded | Order 787470 instead |
| 1 | 787470 | Ferrari Active Roll Bar - 787470 | $8,235.66 | Special order, ships in 7-14 days |
| 1 | 787469 | Ferrari Rollbar - 787469 | $8,868.82 | Special order, ships in 7-14 days |
| 2 | 15213834 | Ferrari Screw - 15213834 | $2.82 | Available, ships in 3-6 days |
| 3 | 219344 | Ferrari Washer D8.5x24x - 219344 | Superseded | Order 124338 instead |
| 4 | 791038 | Ferrari Compl. RH Rear Belt Winder Mounting Bracket - 791038 | $100.93 | Special order, ships in 7-14 days |
| 5 | 791037 | Ferrari Compl. LH Rear Belt Winder Mounting Bracket - 791037 | $100.93 | Special order, ships in 7-14 days |
| 6 | 16043434 | Ferrari Screw M8 x 20 - 16043434 | $0.40 | Available, ships in 3-6 days |
| 7 | 16043634 | Ferrari Screw M8 x 25 - 16043634 | $0.40 | Available, ships in 3-6 days |
