Ferrari Portofino M — [VEHICLE TRIM] - E.13.02 - ROOF - KINEMATICS (diagram 0110)
Exploded view of the [vehicle trim] - e.13.02 - roof - kinematics on the Ferrari Portofino M, with 34 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Portofino M [VEHICLE TRIM] - E.13.02 - ROOF - KINEMATICS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/portofino-m/0110.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 80415900 | Ferrari Screw - 80415900 | $32.60 | Available, ships in 3-6 days | |
| 12640606 | Ferrari Washer - 12640606 | Superseded | Order 12640678 instead | |
| 12640608 | Ferrari Washer - 12640608 | Superseded | Order 12640678 instead | |
| 12640677 | Ferrari Washer - 12640677 | Superseded | Order 12640678 instead | |
| 124338 | Ferrari Washer D. 8 - 25 x 3 - 124338 | $14.55 | Available, ships in 3-6 days | |
| 1 | 762702 | Ferrari Compl. Front Lock - 762702 | $4,842.43 | Special order, ships in 7-14 days |
| 2 | 768592 | Ferrari Front Lock Striker Sensor Kit - Roof - 768592 | $590.91 | Available, ships in 3-6 days |
| 3 | 70001687 | Ferrari Bar Fastener Bracket Kit - 70001687 | $78.76 | Available, ships in 3-6 days |
| 4 | 768594 | Ferrari RH Tonneau Cover And Luggage - 768594 | $12,083.83 | Contact us to order |
| 5 | 768593 | Ferrari LH Tonneau Cover And Luggage - 768593 | $12,083.83 | Contact us to order |
| 6 | 763320 | Ferrari Tc Wiring Harness Kit. RH An - 763320 | $664.78 | Special order, ships in 7-14 days |
| 7 | 860504 | Ferrari Longitudinal Centring Bracke - 860504 | $320.06 | Special order, ships in 7-14 days |
| 8 | 860505 | Ferrari Longitudinal Centring Guide - 860505 | $270.83 | Special order, ships in 7-14 days |
| 9 | 89257400 | Ferrari Compl. RH Striker - 89257400 | $984.88 | Special order, ships in 7-14 days |
| 10 | 89257300 | Ferrari Compl. LH Striker - 89257300 | $1,206.48 | Special order, ships in 7-14 days |
| 11 | 80676200 | Ferrari Roof Lock Striker Plate Cover - 80676200 | $68.92 | Special order, ships in 7-14 days |
| 12 | 770034 | Ferrari RH Latch Compl. With Sensor - 770034 | $393.93 | Special order, ships in 7-14 days |
| 13 | 762718 | Ferrari RH Latch - 762718 | $88.61 | Special order, ships in 7-14 days |
| 14 | 860534 | Ferrari Travel Limit Mount Kit - 860534 | $184.65 | Special order, ships in 7-14 days |
| 15 | 780905 | Ferrari RH Roof Mounting Bracket - 780905 | $56.60 | Special order, ships in 7-14 days |
| 16 | 780904 | Ferrari LH Roof Mounting Bracket - 780904 | $56.60 | Special order, ships in 7-14 days |
| 17 | 815633 | Ferrari High Wear Protective Film - 815633 | $467.80 | Special order, ships in 7-14 days |
| 17 | 89352800 | Ferrari High Wear Protective Film - 89352800 | $467.80 | Special order, ships in 7-14 days |
| 18 | 11617624 | Ferrari Screw - 11617624 | Superseded | Order 16287224 instead |
| 18 | 16287224 | Ferrari Screw M8x25 - 16287224 | $0.82 | Available, ships in 3-6 days |
| 19 | 219344 | Ferrari Washer D8.5x24x - 219344 | Superseded | Order 124338 instead |
| 20 | 812003 | Ferrari Piastra Scontrino Parabrezza - 812003 | $19.19 | Special order, ships in 7-14 days |
| 21 | 84503800 | Ferrari Shim Kit For Adjusting Roof Relative To Windscreen - 84503800 | $78.66 | Special order, ships in 7-14 days |
| 22 | 12646624 | Ferrari Washer 6.15-15x1.5 - 12646624 | $0.40 | Available, ships in 3-6 days |
| 23 | 14305334 | Ferrari Screw M6 x 20 - 14305334 | $0.38 | Available, ships in 3-6 days |
| 24 | 768570 | Ferrari Complete RH Rear Bracket - 768570 | $46.75 | Special order, ships in 7-14 days |
| 25 | 768568 | Ferrari Complete LH Rear Bracket - 768568 | $46.75 | Special order, ships in 7-14 days |
| 26 | 231618 | Ferrari Allen Head Screw M6x20 TCEI - 231618 | $0.57 | Available, ships in 3-6 days |
| 27 | 12640678 | Ferrari Washer 6.15x25x2 - 12640678 | $3.47 | Available, ships in 3-6 days |
