Ferrari Portofino M — [VEHICLE TRIM] - E.13.04 - ROOF - HYDRAULICS (diagram 0112)
Exploded view of the [vehicle trim] - e.13.04 - roof - hydraulics on the Ferrari Portofino M, with 10 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Portofino M [VEHICLE TRIM] - E.13.04 - ROOF - HYDRAULICS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/portofino-m/0112.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 1 | 762708 | Ferrari Compl. Hydraulic Unit - 762708 | $18,282.29 | Contact us to order |
| 2 | 762707 | Ferrari Roof Wiring Harness - 762707 | $1,748.17 | Special order, ships in 7-14 days |
| 3 | 762717 | Ferrari Compl. Rear Screen ECU - 762717 | $2,462.24 | Special order, ships in 7-14 days |
| 4 | 89320800 | Ferrari Incapsulamento Sup. Pompa RH - 89320800 | $270.83 | Special order, ships in 7-14 days |
| 5 | 762711 | Ferrari RH Front Roof Piston Kit - 762711 | $5,658.49 | Special order, ships in 7-14 days |
| 6 | 762710 | Ferrari LH Front Roof Piston Kit - 762710 | $5,658.49 | Special order, ships in 7-14 days |
| 7 | 762713 | Ferrari RH Rear Roof Piston Kit - 762713 | $5,658.49 | Special order, ships in 7-14 days |
| 8 | 762712 | Ferrari LH Rear Roof Piston Kit - 762712 | $5,658.49 | Special order, ships in 7-14 days |
| 9 | 762716 | Ferrari RH Tonneau Cover Piston Kit - 762716 | $5,658.49 | Special order, ships in 7-14 days |
| 10 | 762714 | Ferrari LH Tonneau Cover Piston Kit - 762714 | $5,658.49 | Special order, ships in 7-14 days |
