Ferrari Portofino M — [VEHICLE TRIM] - E.19 - INTERNAL CABIN INSULATION (diagram 0118)
Exploded view of the [vehicle trim] - e.19 - internal cabin insulation on the Ferrari Portofino M, with 10 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Portofino M [VEHICLE TRIM] - E.19 - INTERNAL CABIN INSULATION exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/portofino-m/0118.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 781171 | Ferrari Compl. Firewall Insulation - 781171 | $660.87 | Special order, ships in 7-14 days | |
| 88963200 | Ferrari Isolante Parafiamma Cpl - 88963200 | $587.44 | Special order, ships in 7-14 days | |
| 1 | 781099 | Ferrari Tunnel Insulation - 781099 | $177.25 | Special order, ships in 7-14 days |
| 2 | 769105 | Ferrari Foam - 769105 | $98.46 | Special order, ships in 7-14 days |
| 3 | 928016 | Ferrari Compl. Firewall Insulation - 928016 | Superseded | Order 781171 instead |
| 3 | 860680 | Ferrari Isolante Parafiamma Cpl - 860680 | $590.91 | Special order, ships in 7-14 days |
| 4 | 68808600 | Ferrari Button - 68808600 | $2.59 | Available, ships in 3-6 days |
| 5 | 67315400 | Ferrari Washer - 67315400 | $0.82 | Special order, ships in 7-14 days |
| 6 | 867649 | Ferrari RH Rear Seat Base Closure In - 867649 | $9.08 | Special order, ships in 7-14 days |
| 7 | 867648 | Ferrari LH Rear Seat Base Closure In - 867648 | $9.08 | Special order, ships in 7-14 days |
