Ferrari Portofino M — [VEHICLE TRIM] - E.25 - WINDSCREEN (diagram 0124)
Exploded view of the [vehicle trim] - e.25 - windscreen on the Ferrari Portofino M, with 26 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Portofino M [VEHICLE TRIM] - E.25 - WINDSCREEN exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/portofino-m/0124.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 768977 | Ferrari Battery Cover - 768977 | Superseded | Order 768976 instead | |
| 88960700 | Ferrari Compl. Battery Cover - 88960700 | Superseded | Order 88960600 instead | |
| 88960800 | Ferrari Compl. Battery Cover - 88960800 | Superseded | Order 88960600 instead | |
| 14433121 | Ferrari Screw - 14433121 | Superseded | Order 231617 instead | |
| 124338 | Ferrari Washer D. 8 - 25 x 3 - 124338 | $14.55 | Available, ships in 3-6 days | |
| 768978 | Ferrari Water Basket - 768978 | Superseded | Order 768976 instead | |
| 1 | 862250 | Ferrari Windscreen - 862250 | $5,809.36 | Contact us to order |
| 1 | 862293 | Ferrari Windscreen - 862293 | $3,122.49 | Contact us to order |
| 2 | 781275 | Ferrari LH Front Pillar Seal - 781275 | $161.94 | Special order, ships in 7-14 days |
| 2 | 781276 | Ferrari RH Front Pillar Seal - 781276 | $161.94 | Special order, ships in 7-14 days |
| 3 | 836167 | Ferrari RH C Pillar Soundproofing Ni - 836167 | $10.56 | Special order, ships in 7-14 days |
| 3 | 836165 | Ferrari RH Reflex Box Cover Grille - 836165 | $10.56 | Special order, ships in 7-14 days |
| 4 | 785316 | Ferrari Compl. RH Underwindscreen Tr - 785316 | $763.27 | Special order, ships in 7-14 days |
| 4 | 88959900 | Ferrari Compl. RH Underwindscreen Tr - 88959900 | $689.41 | Special order, ships in 7-14 days |
| 5 | 88959400 | Ferrari Compl. LH Underwindscreen Tr - 88959400 | $935.64 | Special order, ships in 7-14 days |
| 5 | 785314 | Ferrari Mostrina Sottoparabrezza Sx - 785314 | $590.91 | Special order, ships in 7-14 days |
| 6 | 82742000 | Ferrari Ring - 82742000 | $110.61 | Special order, ships in 7-14 days |
| 7 | 88271700 | Ferrari Underwindscreen Tray Water Pipe - 88271700 | $0.92 | Special order, ships in 7-14 days |
| 8 | 86232500 | Ferrari Button - 86232500 | $5.65 | Available, ships in 3-6 days |
| 9 | 256490 | Ferrari Screw TBEI M5 x 16 - 256490 | $3.91 | Available, ships in 3-6 days |
| 10 | 768976 | Ferrari Battery Cover - 768976 | $189.56 | Special order, ships in 7-14 days |
| 10 | 88960600 | Ferrari Compl. Battery Cover - 88960600 | $204.34 | Special order, ships in 7-14 days |
| 11 | 768078 | Ferrari Compl. RH Underwindscreen Tr - 768078 | $66.45 | Special order, ships in 7-14 days |
| 11 | 919347 | Ferrari Complete LH Under Windscreen Tray Fastener Bracket - 919347 | $51.67 | Special order, ships in 7-14 days |
| 12 | 231617 | Ferrari Screw M6 x 18 TCEI - 231617 | Superseded | Order 14433124 instead |
| 13 | 219344 | Ferrari Washer D8.5x24x - 219344 | Superseded | Order 124338 instead |
