Ferrari Portofino M — [VEHICLE TRIM] - E.29.02 - DOORS - OPENING MECHANISMS AND HINGES (diagram 0129)

Exploded view of the [vehicle trim] - e.29.02 - doors - opening mechanisms and hinges on the Ferrari Portofino M, with 46 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari Portofino M [VEHICLE TRIM] - E.29.02 - DOORS - OPENING MECHANISMS AND HINGES exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
82629100Ferrari Cable Grommet - 82629100SupersededOrder 898656 instead
88957300Ferrari Inner Door Handle Bowden Cab - 88957300SupersededOrder 895674 instead
85730900Ferrari LH Door Lock LHD - 85730900SupersededOrder 785970 instead
85731000Ferrari LH Door Lock RHD - 85731000$318.19Special order, ships in 7-14 days
69979110Ferrari LH External Door Handle - 69979110SupersededOrder 69979100 instead
85730800Ferrari RH Door Lock LHD - 85730800SupersededOrder 785971 instead
85731100Ferrari RH Door Lock RHD - 85731100SupersededOrder 785975 instead
69978910Ferrari RH External Door Handle - 69978910SupersededOrder 69978900 instead
952826Ferrari Tirante Arresto Porta Contin - 952826SupersededOrder 69877300 instead
1785970Ferrari LH Door Lock LHD - 785970$243.40Special order, ships in 7-14 days
1785974Ferrari LH Door Lock RHD - 785974$243.40Special order, ships in 7-14 days
1785971Ferrari RH Door Lock LHD - 785971$243.40Special order, ships in 7-14 days
1785975Ferrari RH Door Lock RHD - 785975$243.40Special order, ships in 7-14 days
285052500Ferrari Door Lock Striker Plate - 85052500$29.48Special order, ships in 7-14 days
385133400Ferrari Screw TSEI M8 x 20 - 85133400$1.30Available, ships in 3-6 days
484872900Ferrari Screw - 84872900$0.82Available, ships in 3-6 days
569877100Ferrari Door Bowden Cable - 69877100$68.83Special order, ships in 7-14 days
682936500Ferrari Protective Sheath For Internal Handle Bowden Cable - 82936500$4.39Special order, ships in 7-14 days
7898656Ferrari Cable Grommet - 898656$6.10Special order, ships in 7-14 days
882936400Ferrari Sheath - 82936400$8.59Special order, ships in 7-14 days
969877300Ferrari Door Arrester Tie-Rod - 69877300$108.31Special order, ships in 7-14 days
1083897000Ferrari Door Arrester Tie-Rod Seal - 83897000$24.32Special order, ships in 7-14 days
1181327900Ferrari LH Seal - 81327900$22.35Special order, ships in 7-14 days
1181328000Ferrari RH Seal - 81328000$22.35Special order, ships in 7-14 days
12768209Ferrari LH Outer Door Handle Module - 768209$393.93Special order, ships in 7-14 days
12768210Ferrari RH Outer Door Handle Module - 768210$393.93Special order, ships in 7-14 days
1380821900Ferrari Door Handle Spacer - 80821900$12.21Special order, ships in 7-14 days
14780879Ferrari Compl. Latch Mounting - 780879$295.43Special order, ships in 7-14 days
1489223500Ferrari Porta Nottolino Cpl - 89223500$295.43Special order, ships in 7-14 days
1569979100Ferrari LH External Door Handle - 69979100$81.11Special order, ships in 7-14 days
1569978900Ferrari RH External Door Handle - 69978900$81.11Special order, ships in 7-14 days
1680365900Ferrari Screw M4 x 12 TSEI - 80365900$0.31Available, ships in 3-6 days
1714506587Ferrari Rubber Grommet - 14506587$0.38Available, ships in 3-6 days
1814059121Ferrari Nut M5 - 14059121$0.31Available, ships in 3-6 days
1988916600Ferrari LH Door Waterproof Membrane - 88916600$86.15Special order, ships in 7-14 days
1988916500Ferrari RH Door Waterproof Membrane - 88916500$86.15Special order, ships in 7-14 days
2088938500Ferrari Front RH Door Membrane - 88938500$41.82Special order, ships in 7-14 days
2088938400Ferrari LH Front Door Membrane - 88938400$41.82Special order, ships in 7-14 days
2114569480Ferrari Clip 10x3.8 Black - 14569480$0.54Available, ships in 3-6 days
2288007300Ferrari Door Handle Spacer LHD - 88007300$6.54Special order, ships in 7-14 days
23248061Ferrari Clip - 248061$4.12Available, ships in 3-6 days
24291283Ferrari Clip - 291283$1.09Special order, ships in 7-14 days
25217854Ferrari CLAMP - 217854$0.52Available, ships in 3-6 days
2613832101Ferrari Flanged Nut M6 - 13832101$0.27Available, ships in 3-6 days
27895674Ferrari Inner Door Handle Bowden Cab - 895674$132.94Special order, ships in 7-14 days
2883595400Ferrari Door Striker Plate Film - 83595400$7.40Special order, ships in 7-14 days

All Portofino M diagrams
