Ferrari Portofino M — [VEHICLE TRIM] - E.36 - REAR LID TRIM (diagram 0137)

Exploded view of the [vehicle trim] - e.36 - rear lid trim on the Ferrari Portofino M, with 65 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari Portofino M [VEHICLE TRIM] - E.36 - REAR LID TRIM exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
10413870Ferrari Belleville Washer - 10413870SupersededOrder 12646724 instead
80797900Ferrari Luggage Compartment Lock - 80797900Price on requestContact us for price and availability
82035300Ferrari Luggage Compartment Lock - 82035300SupersededOrder 86488700 instead
86263600Ferrari Luggage Compartment Lock - 86263600SupersededOrder 86488700 instead
86263800Ferrari Luggage Compartment Lock - 86263800SupersededOrder 86488800 instead
15642501Ferrari Screw - 15642501SupersededOrder 15902601 instead
86574400Ferrari Screw - 86574400SupersededOrder 86876500 instead
10519201Ferrari Washer - 10519201SupersededOrder 10519224 instead
10519281Ferrari Washer - 10519281SupersededOrder 10519224 instead
12601570Ferrari Washer - 12601570SupersededOrder 12646724 instead
12601571Ferrari Washer - 12601571SupersededOrder 12646724 instead
12646721Ferrari Washer - 12646721SupersededOrder 12646724 instead
156093Ferrari Washer - 156093SupersededOrder 12646778 instead
1783908Ferrari Luggage Compartment Lid Trim - 783908$685.34Special order, ships in 7-14 days
188900000Ferrari Luggage Compartment Lid Trim - 88900000$636.39Special order, ships in 7-14 days
214591687Ferrari Fixing Button - 14591687$0.13Available, ships in 3-6 days
388900100Ferrari Luggage Compartment Lid Hand - 88900100$17.42Special order, ships in 7-14 days
413311077Ferrari Screw M5 x 16 TSCIC - 13311077$0.27Available, ships in 3-6 days
588846800Ferrari Scontrino Cofano Baule Dx - 88846800$80.75Special order, ships in 7-14 days
588846900Ferrari Scontrino Cofano Baule Sx - 88846900$80.75Special order, ships in 7-14 days
689242100Ferrari LH Luggage Compartment Lid P - 89242100$31.80Special order, ships in 7-14 days
689242200Ferrari RH Luggage Compartment Lid P - 89242200$31.80Special order, ships in 7-14 days
782113500Ferrari Screw Torx M6 x 18 with Washer D. 15 - 82113500$5.86Available, ships in 3-6 days
8856582Ferrari Spacer Block - 856582$125.37Available, ships in 3-6 days
986488700Ferrari Rear Lid Lock - 86488700$1,248.34Special order, ships in 7-14 days
986488800Ferrari Rear Lid Lock - 86488800$1,248.34Special order, ships in 7-14 days
1016287127Ferrari Screw 8x20 - 16287127$0.92Special order, ships in 7-14 days
1112646724Ferrari Washer 8.45-20x2 - 12646724$0.19Available, ships in 3-6 days
12804183Ferrari Compl. License Plate Light S - 804183$3,823.17Special order, ships in 7-14 days
12865754Ferrari Compl. License Plate Light S - 865754$3,293.98Special order, ships in 7-14 days
1289054000Ferrari Compl. License Plate Light S - 89054000$905.64Special order, ships in 7-14 days
1386595700Ferrari Luggage Compartment Lid Striker Motor - 86595700$565.68Special order, ships in 7-14 days
1482271400Ferrari Screw with Washer M8 x 25 TE - 82271400$2.59Available, ships in 3-6 days
1555024105Ferrari Italian Flag Badge - 55024105$1,076.99Special order, ships in 7-14 days
1584542200Ferrari Italian Flag Badge - 84542200Price on requestSpecial order, ships in 7-14 days
1584706300Ferrari Italian Flag Badge - 84706300SupersededOrder 988640 instead
15988640Ferrari Italian Flag Badge - 988640$835.97Available, ships in 3-6 days
1685691900Ferrari Screw M5 x 8 TBFTX - 85691900$0.65Available, ships in 3-6 days
1712638124Ferrari Washer - 12638124$0.08Available, ships in 3-6 days
1712638101Ferrari Washer White - 12638101SupersededOrder 12638124 instead
1870006420Ferrari Cavallino Rampante Badge - 70006420$70.96Special order, ships in 7-14 days
1882059100Ferrari Rear Motif Prancing Horse H100mm - 82059100$134.61Special order, ships in 7-14 days
1962790300Ferrari Nyloc Nut 4x5 - 62790300$0.52Available, ships in 3-6 days
2010519224Ferrari Washer - 10519224$0.12Available, ships in 3-6 days
2160995100Ferrari Washer - 60995100$5.44Available, ships in 3-6 days
2270006277Ferrari Badge - 70006277$125.37Special order, ships in 7-14 days
2263482200Ferrari Rear Emblem / Motif - 63482200$114.05In stock
2384952000Ferrari Cosmetic Cap - 84952000$16.45Available, ships in 3-6 days
2489144000Ferrari Washer - 89144000$0.79Available, ships in 3-6 days
25816293Ferrari LH Luggage Compartment Lid Kinematics - 816293$293.71Special order, ships in 7-14 days
25816292Ferrari RH Luggage Compartment Lid Kinematics - 816292$293.71Special order, ships in 7-14 days
26210246Ferrari Screw 8x25 - 210246$2.82Available, ships in 3-6 days
2712646778Ferrari Washer - 12646778$0.89In stock
28827108Ferrari Gas Strut - 827108$80.48Special order, ships in 7-14 days
2987731010Ferrari Vehicle Opt. List Holder - 87731010$614.67Special order, ships in 7-14 days
3086876500Ferrari Screw M4 x 12 TBEI - 86876500$7.84Special order, ships in 7-14 days
3065752800Ferrari Screw M4 x 10 TBEI - 65752800$4.12Available, ships in 3-6 days
31306715Ferrari Magnetic Battery Conditioner Jack - 306715$293.71Special order, ships in 7-14 days
32307799Ferrari Light - 307799$87.40Special order, ships in 7-14 days
3367080000Ferrari Trunk Compartment Opening Block - 67080000$100.34Special order, ships in 7-14 days
3415902601Ferrari Screw - 15902601$0.12Special order, ships in 7-14 days
35782753Ferrari Rear Camera - 782753$2,485.70Special order, ships in 7-14 days
35818615Ferrari Surround Camera - 818615$1,967.03Special order, ships in 7-14 days
36781963Ferrari Bracket - 781963$23.86Special order, ships in 7-14 days
3766403900Ferrari Emergency Trunk Release Handle - 66403900$74.00In stock
