Ferrari Portofino M — [VEHICLE TRIM] - E.47.04 - DASHBOARD - TRIM -Applicable for RHD- (diagram 0152)

Exploded view of the [vehicle trim] - e.47.04 - dashboard - trim -applicable for rhd- on the Ferrari Portofino M, with 83 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.

Ferrari Portofino M [VEHICLE TRIM] - E.47.04 - DASHBOARD - TRIM -Applicable for RHD- exploded diagram

Parts on this diagram

Ref.Part numberPartPriceAvailability
170007303Ferrari COMPL. LOWER CENTRE DASHBOARD TRIM - 70007303Price on requestContact us for price and availability
1758665Ferrari Compl. Lower Centre Dashboard Trim - 758665$3,097.73Special order, ships in 7-14 days
1795217Ferrari Compl. Lower Centre Dashboard Trim - 795217$2,846.82Special order, ships in 7-14 days
1819992Ferrari COMPL. LOWER CENTRE DASHBOARD TRIM - 819992Price on requestContact us for price and availability
289089800Ferrari Defroster Control Surround - 89089800Price on requestContact us for price and availability
389390200Ferrari Compl. Binnacle - 89390200$2,087.03Special order, ships in 7-14 days
468002000Ferrari Rubber Pad - 68002000$7.40Special order, ships in 7-14 days
570006616Ferrari LH CENTRE SURROUND - 70006616Price on requestContact us for price and availability
570006617Ferrari LH CENTRE SURROUND - 70006617Price on requestContact us for price and availability
570007258Ferrari LH CENTRE SURROUND - 70007258Price on requestContact us for price and availability
570007259Ferrari LH CENTRE SURROUND - 70007259Price on requestContact us for price and availability
5768385Ferrari LH Centre Surround - 768385$4,333.57Special order, ships in 7-14 days
5768460Ferrari LH Centre Surround - 768460$1,403.46Special order, ships in 7-14 days
5768465Ferrari LH Centre Surround - 768465$1,206.48Special order, ships in 7-14 days
5768466Ferrari LH Centre Surround - 768466$4,333.57Special order, ships in 7-14 days
870007304Ferrari COMPL. LATERAL GLOVE COMPARTMENT TRIM - 70007304Price on requestContact us for price and availability
8761862Ferrari Compl. Lateral Glove Compartment Trim - 761862$1,132.62Special order, ships in 7-14 days
8795685Ferrari Compl. Lateral Glove Compartment Trim - 795685$1,034.12Special order, ships in 7-14 days
8819994Ferrari COMPL. LATERAL GLOVE COMPARTMENT TRIM - 819994Price on requestContact us for price and availability
988036300Ferrari COMPL. STEERING COLUMN SHIELD DASHBOARD BELLOW - 88036300$614.67Special order, ships in 7-14 days
10761907Ferrari Compl. Fuse Box Cover - 761907$763.27Special order, ships in 7-14 days
10798560Ferrari Compl. Fuse Box Cover - 798560$714.03Special order, ships in 7-14 days
10820008Ferrari COMPL. FUSE BOX COVER - 820008Price on requestContact us for price and availability
1167003800Ferrari Bonnet Release Handle - 67003800$122.92Special order, ships in 7-14 days
1270007305Ferrari COMPL. DRIVER SIDE UNDERDASHBOARD TRIM PANEL - 70007305Price on requestContact us for price and availability
1270007306Ferrari COMPL. DRIVER SIDE UNDERDASHBOARD TRIM PANEL - 70007306Price on requestContact us for price and availability
12761866Ferrari Compl. Driver Side Underdashboard Trim Panel - 761866$4,565.72Special order, ships in 7-14 days
12761902Ferrari Compl. Driver Side Underdashboard Trim Panel - 761902$4,321.83Special order, ships in 7-14 days
12797648Ferrari Compl. Driver Side Underdashboard Trim Panel - 797648$4,554.00Special order, ships in 7-14 days
12797652Ferrari Compl. Driver Side Underdashboard Trim Panel - 797652$4,274.93Special order, ships in 7-14 days
12819997Ferrari COMPL. DRIVER SIDE UNDERDASHBOARD TRIM PANEL - 819997Price on requestContact us for price and availability
12820000Ferrari COMPL. DRIVER SIDE UNDERDASHBOARD TRIM PANEL - 820000Price on requestContact us for price and availability
13783715Ferrari A/C Dash Vent - 783715$418.56Special order, ships in 7-14 days
1370007260Ferrari AC VENT - 70007260Price on requestContact us for price and availability
1488866300Ferrari RH Defroster Vent Seal - 88866300$105.03Special order, ships in 7-14 days
1588866200Ferrari LH Defroster Vent Seal - 88866200$105.03Special order, ships in 7-14 days
1689090800Ferrari Central Diffuser Surround - 89090800$1,329.59Special order, ships in 7-14 days
1789391700Ferrari Compl. Upper Dashboard - 89391700$13,713.62Contact us to order
1889091300Ferrari RH Dash Speaker Grille - 89091300$31.99Special order, ships in 7-14 days
1989091200Ferrari LH Dash Speaker Grille - 89091200$31.99Special order, ships in 7-14 days
2089248600Ferrari Cover Posteriore Nit - 89248600$98.46Special order, ships in 7-14 days
21785285Ferrari Centre Dash Speaker Grille - 785285$174.80Special order, ships in 7-14 days
21807943Ferrari Centre Dash Speaker Grille - 807943$118.16Special order, ships in 7-14 days
21807948Ferrari Centre Dash Speaker Grille - 807948$189.56Special order, ships in 7-14 days
2189392100Ferrari Centre Dash Speaker Grille - 89392100$174.80Special order, ships in 7-14 days
2289391800Ferrari Compl. Passenger Side Cosmet - 89391800$566.30Special order, ships in 7-14 days
2288017500Ferrari Passenger Display Surround - 88017500$270.83Special order, ships in 7-14 days
23763737Ferrari Nit Control Surround - 763737$393.93Special order, ships in 7-14 days
23763738Ferrari Nit Control Surround - 763738$393.93Special order, ships in 7-14 days
2470006618Ferrari TFT CONTROL PANEL SURROUND - 70006618Price on requestContact us for price and availability
2470006619Ferrari TFT CONTROL PANEL SURROUND - 70006619Price on requestContact us for price and availability
2470007261Ferrari TFT CONTROL PANEL SURROUND - 70007261Price on requestContact us for price and availability
2470007262Ferrari TFT CONTROL PANEL SURROUND - 70007262Price on requestContact us for price and availability
24803100Ferrari Tft Control Panel Surround - 803100$1,748.17Special order, ships in 7-14 days
24863043Ferrari Tft Control Panel Surround - 863043$393.93Special order, ships in 7-14 days
24863044Ferrari Tft Control Panel Surround - 863044$1,748.17Special order, ships in 7-14 days
2489391200Ferrari Tft Control Panel Surround - 89391200$393.93Special order, ships in 7-14 days
2588147800Ferrari Front Frame - 88147800$418.56Special order, ships in 7-14 days
26980521Ferrari Dashboard Badge - 980521$238.82Special order, ships in 7-14 days
27759861Ferrari Compl. LH Centre Fascia - 759861SupersededOrder 890488 instead
27759873Ferrari Compl. LH Centre Fascia - 759873SupersededOrder 890493 instead
27759877Ferrari Compl. LH Centre Fascia - 759877SupersededOrder 890490 instead
27759879Ferrari Compl. LH Centre Fascia - 759879SupersededOrder 890494 instead
27768384Ferrari Compl. LH Centre Fascia - 768384SupersededOrder 890491 instead
27768386Ferrari Compl. LH Centre Fascia - 768386SupersededOrder 890495 instead
27768387Ferrari Compl. LH Centre Fascia - 768387SupersededOrder 890492 instead
27768388Ferrari Compl. LH Centre Fascia - 768388SupersededOrder 890496 instead
27890488Ferrari Compl. LH Centre Fascia - 890488$2,666.25Special order, ships in 7-14 days
27890490Ferrari Compl. LH Centre Fascia - 890490$2,462.24Special order, ships in 7-14 days
27890491Ferrari Compl. LH Centre Fascia - 890491$5,625.67Special order, ships in 7-14 days
27890492Ferrari Compl. LH Centre Fascia - 890492$5,625.67Special order, ships in 7-14 days
27890493Ferrari Compl. LH Centre Fascia - 890493$2,581.84Special order, ships in 7-14 days
27890494Ferrari Compl. LH Centre Fascia - 890494$2,345.00Special order, ships in 7-14 days
27890495Ferrari Compl. LH Centre Fascia - 890495$5,538.89Special order, ships in 7-14 days
27890496Ferrari Compl. LH Centre Fascia - 890496$5,538.89Special order, ships in 7-14 days
2889199000Ferrari Surround - 89199000$51.67Special order, ships in 7-14 days
2889199500Ferrari Surround - 89199500$39.37Special order, ships in 7-14 days
29785286Ferrari Antenna Surround - 785286$36.92Special order, ships in 7-14 days
29887487Ferrari Antenna Surround - 887487$66.45Special order, ships in 7-14 days
3084001400Ferrari Joystick Panel - 84001400$120.46Special order, ships in 7-14 days
3187691000Ferrari Mostrina Tasto Engine - 87691000$344.21Special order, ships in 7-14 days
32813124Ferrari Starlock Raymond 011876004 - 813124Price on requestContact us for price and availability
35179309Ferrari ADHESIVE FOAM - 179309$8.28Available, ships in 3-6 days

All Portofino M diagrams
