Ferrari Portofino M — [VEHICLE TRIM] - E.49 - INNER TRIM (ABOVE BELTLINE) (diagram 0159)
Exploded view of the [vehicle trim] - e.49 - inner trim (above beltline) on the Ferrari Portofino M, with 41 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Portofino M [VEHICLE TRIM] - E.49 - INNER TRIM (ABOVE BELTLINE) exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/portofino-m/0159.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 81911200 | Ferrari Screw - 81911200 | Superseded | Order 85692200 instead | |
| 68176300 | Ferrari Screw 5x12 - 68176300 | Superseded | Order 85692200 instead | |
| 11566224 | Ferrari Screw 5x14 - 11566224 | $0.77 | Available, ships in 3-6 days | |
| 1 | 956850 | Ferrari Compl. Upper Windscreen Cros - 956850 | $2,609.97 | Special order, ships in 7-14 days |
| 1 | 956853 | Ferrari Compl. Upper Windscreen Cros - 956853 | Price on request | Contact us for price and availability |
| 2 | 766777 | Ferrari Compl. RH Pillar - 766777 | Superseded | Order 896074 instead |
| 2 | 785225 | Ferrari Compl. RH Pillar - 785225 | Superseded | Order 896077 instead |
| 2 | 896074 | Ferrari Compl. RH Pillar - 896074 | $320.06 | Special order, ships in 7-14 days |
| 2 | 896077 | Ferrari Compl. RH Pillar - 896077 | $320.06 | Special order, ships in 7-14 days |
| 3 | 766774 | Ferrari Compl. LH Pillar - 766774 | Superseded | Order 896069 instead |
| 3 | 785223 | Ferrari Compl. LH Pillar - 785223 | Superseded | Order 896076 instead |
| 3 | 896069 | Ferrari Compl. LH Pillar - 896069 | $320.06 | Special order, ships in 7-14 days |
| 3 | 896076 | Ferrari Compl. LH Pillar - 896076 | $320.06 | Special order, ships in 7-14 days |
| 4 | 68700200 | Ferrari Fixing Clip - 68700200 | $10.68 | Special order, ships in 7-14 days |
| 5 | 85833700 | Ferrari SCREW - 85833700 | $0.65 | Available, ships in 3-6 days |
| 6 | 785219 | Ferrari RH Sun Visor - 785219 | $2,063.59 | Special order, ships in 7-14 days |
| 6 | 785220 | Ferrari RH Sun Visor - 785220 | $2,063.59 | Special order, ships in 7-14 days |
| 6 | 785221 | Ferrari RH Sun Visor - 785221 | $2,060.69 | Special order, ships in 7-14 days |
| 6 | 785222 | Ferrari RH Sun Visor - 785222 | $2,060.69 | Special order, ships in 7-14 days |
| 6 | 785346 | Ferrari RH Sun Visor - 785346 | $2,271.45 | Special order, ships in 7-14 days |
| 6 | 785456 | Ferrari RH Sun Visor - 785456 | $2,060.69 | Special order, ships in 7-14 days |
| 6 | 785458 | Ferrari RH Sun Visor - 785458 | $2,060.69 | Special order, ships in 7-14 days |
| 6 | 785461 | Ferrari RH Sun Visor - 785461 | $2,271.45 | Special order, ships in 7-14 days |
| 6 | 785462 | Ferrari RH Sun Visor - 785462 | $2,060.69 | Special order, ships in 7-14 days |
| 6 | 785467 | Ferrari RH Sun Visor - 785467 | $2,060.69 | Special order, ships in 7-14 days |
| 6 | 785470 | Ferrari RH Sun Visor - 785470 | $2,060.69 | Special order, ships in 7-14 days |
| 6 | 89108600 | Ferrari RH Sun Visor - 89108600 | $2,248.03 | Special order, ships in 7-14 days |
| 7 | 785345 | Ferrari LH Sun Visor - 785345 | $2,060.69 | Special order, ships in 7-14 days |
| 7 | 785466 | Ferrari LH Sun Visor - 785466 | $2,084.11 | Special order, ships in 7-14 days |
| 7 | 785469 | Ferrari LH Sun Visor - 785469 | $2,060.69 | Special order, ships in 7-14 days |
| 7 | 838280 | Ferrari LH Sun Visor - 838280 | $2,060.69 | Special order, ships in 7-14 days |
| 7 | 838282 | Ferrari LH Sun Visor - 838282 | $2,060.69 | Special order, ships in 7-14 days |
| 7 | 89108500 | Ferrari LH Sun Visor - 89108500 | $1,204.80 | Special order, ships in 7-14 days |
| 8 | 13274411 | Ferrari Screw - 13274411 | $0.17 | Available, ships in 3-6 days |
| 9 | 69396000 | Ferrari Screw M4 X 16 - 69396000 | $1.55 | Special order, ships in 7-14 days |
| 10 | 862900 | Ferrari Mirror Cover - 862900 | $71.38 | Special order, ships in 7-14 days |
| 11 | 85629300 | Ferrari Screw M6 x 20 - 85629300 | $1.17 | Available, ships in 3-6 days |
| 12 | 85692200 | Ferrari SCREW M5 x 12 - 85692200 | $0.65 | Available, ships in 3-6 days |
| 13 | 808943 | Ferrari Sun Visor Clip Cover Trim - 808943 | $110.61 | Special order, ships in 7-14 days |
| 14 | 808944 | Ferrari LH Sun Visor Joint Cover Tri - 808944 | $216.35 | Special order, ships in 7-14 days |
| 14 | 808945 | Ferrari RH Sun Visor Joint Cover Tri - 808945 | $216.35 | Special order, ships in 7-14 days |
