Ferrari Portofino M — [VEHICLE TRIM] - E.55 - WIPERS AND HEADLAMP WASHERS (diagram 0167)
Exploded view of the [vehicle trim] - e.55 - wipers and headlamp washers on the Ferrari Portofino M, with 37 parts. Click a number on the drawing, or use the list, to see each part number, its price and availability, and order it from AW Italian. Not sure it is the right part for your car? Call 800-631-5589, text 732-542-5600 or email info@awitalian.com.
![Ferrari Portofino M [VEHICLE TRIM] - E.55 - WIPERS AND HEADLAMP WASHERS exploded diagram](https://awitalian.com/wp-content/uploads/aw-catalogue/diagrams/portofino-m/0167.webp)
Parts on this diagram
| Ref. | Part number | Part | Price | Availability |
|---|---|---|---|---|
| 977650 | Ferrari Screen Wash Liquid Reservoir - 977650 | Superseded | Order 851829 instead | |
| 106853 | Ferrari Spring Washer 10mm - 106853 | Superseded | Order 12601474 instead | |
| 10516873 | Ferrari Washer - 10516873 | Superseded | Order 12601474 instead | |
| 12601224 | Ferrari Washer - 12601224 | Superseded | Order 12601274 instead | |
| 12601471 | Ferrari Washer - 12601471 | Superseded | Order 12601474 instead | |
| 12605370 | Ferrari Washer - 12605370 | Superseded | Order 12601274 instead | |
| 12605371 | Ferrari Washer - 12605371 | Superseded | Order 12601274 instead | |
| 14498804 | Ferrari Washer - 14498804 | Superseded | Order 14498824 instead | |
| 680232 | Ferrari Washer - 680232 | Superseded | Order 12601274 instead | |
| 12605374 | Ferrari Wavy Washer - 12605374 | Superseded | Order 12601274 instead | |
| 1 | 806682 | Ferrari Gruppo Tergi Gsx - 806682 | $1,231.11 | Special order, ships in 7-14 days |
| 1 | 807730 | Ferrari Windscreen Wiper Assembly - 807730 | $1,899.43 | Special order, ships in 7-14 days |
| 2 | 69771000 | Ferrari Windshield Wiper Arm Pilot Side - 69771000 | $393.93 | Special order, ships in 7-14 days |
| 2 | 80840800 | Ferrari Windshield Wiper Arm Pilot Side - 80840800 | $566.30 | Special order, ships in 7-14 days |
| 3 | 69771100 | Ferrari Windshield Wiper Arm Passenger Side - 69771100 | $295.43 | Special order, ships in 7-14 days |
| 3 | 80840900 | Ferrari Windshield Wiper Arm Passenger Side - 80840900 | $487.74 | Available, ships in 3-6 days |
| 4 | 80539000 | Ferrari Drivers Side Wiper Blade RHD - 80539000 | $240.73 | Available, ships in 3-6 days |
| 4 | 80534900 | Ferrari Wiper Blade Driver Side (Left) - 80534900 | $75.74 | In stock |
| 5 | 69771300 | Ferrari California/Portofino Right Wiper Blade - 69771300 | $72.77 | In stock |
| 5 | 80843800 | Ferrari Passenger Side Wiper Blade RHD - 80843800 | $124.74 | Available, ships in 3-6 days |
| 6 | 10791021 | Ferrari Nut LHD - 10791021 | $1.25 | Available, ships in 3-6 days |
| 7 | 15811787 | Ferrari Protective Cap 17 x 10.5 - 15811787 | $1.53 | Available, ships in 3-6 days |
| 8 | 12640624 | Ferrari Plain Washer 6mm - 12640624 | $0.31 | Available, ships in 3-6 days |
| 9 | 12601474 | Ferrari Wavy Washer 10mm - 12601474 | $0.06 | Available, ships in 3-6 days |
| 10 | 10902824 | Ferrari Screw M6 x 30 - 10902824 | $0.17 | Available, ships in 3-6 days |
| 11 | 781762 | Ferrari Serbatoio Tergi Cpl - 781762 | $566.30 | Special order, ships in 7-14 days |
| 12 | 82198600 | Ferrari Filler Pipe Seal - 82198600 | $44.24 | Special order, ships in 7-14 days |
| 13 | 81633100 | Ferrari Fluid Level Sensor - 81633100 | $240.39 | Special order, ships in 7-14 days |
| 14 | 81633200 | Ferrari Gasket - 81633200 | $50.24 | Special order, ships in 7-14 days |
| 15 | 81632900 | Ferrari Windscreen Washer Pump - 81632900 | $172.84 | Available, ships in 3-6 days |
| 16 | 65511700 | Ferrari Seal For Washer Pump - 65511700 | $9.81 | Available, ships in 3-6 days |
| 17 | 82199100 | Ferrari Screen Wash Liquid Reservoir - 82199100 | Superseded | Order 851829 instead |
| 17 | 851829 | Ferrari Screen Wash Liquid Reservoir - 851829 | $66.35 | Special order, ships in 7-14 days |
| 18 | 82199300 | Ferrari Filter On Cap - 82199300 | $43.74 | Special order, ships in 7-14 days |
| 19 | 88384100 | Ferrari Screen Wash Reservoir Filler - 88384100 | $81.23 | Special order, ships in 7-14 days |
| 20 | 12601274 | Ferrari Wavy Washer 6mm - 12601274 | $1.04 | Available, ships in 3-6 days |
| 21 | 81290900 | Ferrari Screw With Double Washer - 81290900 | $1.42 | In stock |
